Car Wiring Diagrams for BMW X5 E53 facelift (2003-2007)

Wiring diagram nca (31 of 52)

Wiring diagram nca for BMW X5 E53 facelift (2003-2007) (31 of 52)

Get lifetime access to BMW X5 E53 facelift (2003-2007)

BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE COIL SPRING FUSE FUSE HOLDER GRN WIRE GRN/BLK WIRE HOT IN RUN OR START MULTIFUNCTION STEERING WHEEL NCA WIRE RED WIRE STEERING WHEEL HEATER STEERING WHEEL HEATING CONTROL UNIT YEL WIRE

Go to component -> Heated steering wheel circuit -> NCA WIRE

Wiring diagram nca (32 of 52)

Wiring diagram nca for BMW X5 E53 facelift (2003-2007) (32 of 52)

Get lifetime access to BMW X5 E53 facelift (2003-2007)

BLK WIRE BLU/BLK WIRE BLU/BRN WIRE BRN WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM EJECT BOX FUSE GPS ANTENNA GRY/RED WIRE HOT AT ALL TIMES LIGHT MODULE (RIGHT KICK PANEL) NAVIGATION CONTROL MODULE (LEFT REAR PASSENGER COMPARTMENT) NCA WIRE NOT USED ON BOARD MONITOR RADIO RED WIRE RED/WHT WIRE RIGHT FUSE HOLDER WHT WIRE WHT/GRY/YEL WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Navigation circuit -> NCA WIRE

Wiring diagram nca (33 of 52)

Wiring diagram nca for BMW X5 E53 facelift (2003-2007) (33 of 52)

Get lifetime access to BMW X5 E53 facelift (2003-2007)

BCK BLK WIRE BLU WIRE BRN WIRE CUSHION TILT FRONT PASSENGER'S SEAT ADJUSTMENT SWITCH FRT BCK FRT DN FUSE FUSE HOLDER GRN WIRE GRY WIRE HEADREST HEIGHT HOT AT ALL TIMES NCA WIRE PASSENGER'S PASSENGER'S SEAT MOVEMENT SEAT HEIGHT MOTOR MOTOR PASSENGER'S SEAT CUSHION TILT MOTOR PASSENGER'S SEAT HEADREST MOTOR (W/ COMFORT SEATS) PASSENGER'S SEAT LUMBAR SUPPORT SWITCH PASSENGER'S SEATBACK HEAD RECLINER MOTOR (W/ COMFORT SEATS) PASSENGER'S SEATBACK RECLINER MOTOR POSITION RED WIRE SEAT SYSTEM (PASSENGER LUMBAR CIRCUIT) SEATBACK VIO WIRE YEL WIRE

Go to component -> Passenger power seat circuit -> NCA WIRE

Wiring diagram nca (34 of 52)

Wiring diagram nca for BMW X5 E53 facelift (2003-2007) (34 of 52)

Get lifetime access to BMW X5 E53 facelift (2003-2007)

AMPLIFIER BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/ORG WIRE COMPUTER DATA LINES SYSTEM FUSE FUSE HOLDER FUSE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN RUN, ACCY OR LEFT REAR WOOFER SPEAKER NCA WIRE RADIO RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RIGHT FRONT LEFT FRONT HI-RANGE SPEAKER SPEAKER RIGHT MID-RANGE/ HI-RANGE SPEAKER TELEPHONE CONNECTIONS TERMINAL R UNLOADER RELAY VIO/BRN WIRE VIO/WHT WIRE W/ ON-BOARD MONITOR W/O ON-BOARD MONITOR WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY/YEL WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRY WIRE YEL/RED WIRE

Go to component -> Premium radio circuit, with hifi radio (1 of 3) -> NCA WIRE

Wiring diagram nca (35 of 52)

Wiring diagram nca for BMW X5 E53 facelift (2003-2007) (35 of 52)

Get lifetime access to BMW X5 E53 facelift (2003-2007)

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BRN WIRE GRY/BLK WIRE GRY/BRN WIRE LEFT FRONT HI-RANGE SPEAKER LEFT FRONT MID-RANGE SPEAKER LEFT MID-RANGE/ HI-RANGE SPEAKER NCA WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT SPEAKER RIGHT REAR WOOFER SPEAKER VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRY WIRE YEL/RED WIRE

Go to component -> Premium radio circuit, with hifi radio (2 of 3) -> NCA WIRE

Wiring diagram nca (36 of 52)

Wiring diagram nca for BMW X5 E53 facelift (2003-2007) (36 of 52)

Get lifetime access to BMW X5 E53 facelift (2003-2007)

ANTENNA AMPLIFIER AUX SOCKET (2003-06) BLK WIRE BLU/BLK WIRE BLU/BRN WIRE BRN WIRE BRN/RED WIRE CD CHANGER COMPUTER DATA LINES SYSTEM DIVERSITY GENERAL MODULE GRY/RED WIRE MULTI-INFORMATION DISPLAY (MID) NAVIGATION CONTROL MODULE NCA WIRE ON BOARD MONITOR REAR WINDOW RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE ROOF SPOILER AERIAL TV AMPLIFIER VIDEO MODULE (IF EQUIPPED) VIO/WHT WIRE W/ 2002 W/ 2003-06 WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRY/YEL WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Premium radio circuit, with hifi radio (3 of 3) -> NCA WIRE

Wiring diagram nca (37 of 52)

Wiring diagram nca for BMW X5 E53 facelift (2003-2007) (37 of 52)

Get lifetime access to BMW X5 E53 facelift (2003-2007)

AMPLIFIER BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/ORG WIRE COMPUTER DATA LINES SYSTEM COMPUTER TELEPHONE DATA LINES CONNECTIONS SYSTEM FUSE FUSE HOLDER FUSE GRY/RED WIRE HOT AT ALL TIMES HOT IN RUN, ACCY OR LEFT REAR WOOFER SPEAKER NCA WIRE RADIO RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RIGHT REAR WOOFER SPEAKER SUBWOOFER SPEAKER TELEPHONE CONNECTIONS TERMINAL R UNLOADER RELAY VIO/BRN WIRE VIO/WHT WIRE W/ ON-BOARD MONITOR W/O ON-BOARD MONITOR WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY/YEL WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Premium radio circuit, with top hifi radio (1 of 3) -> NCA WIRE

Wiring diagram nca (38 of 52)

Wiring diagram nca for BMW X5 E53 facelift (2003-2007) (38 of 52)

Get lifetime access to BMW X5 E53 facelift (2003-2007)

AMPLIFIER BLK WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE GRY/BLK WIRE GRY/BRN WIRE LEFT FRONT HI-RANGE SPEAKER LEFT FRONT SPEAKER LEFT MID-RANGE/ HI-RANGE SPEAKER NCA WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RIGHT FRONT HI-RANGE SPEAKER RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT SPEAKER RIGHT MID-RANGE/ HI-RANGE SPEAKER VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Premium radio circuit, with top hifi radio (2 of 3) -> NCA WIRE

Wiring diagram nca (39 of 52)

Wiring diagram nca for BMW X5 E53 facelift (2003-2007) (39 of 52)

Get lifetime access to BMW X5 E53 facelift (2003-2007)

ANTENNA AMPLIFIER AUX SOCKET (2003-06) BLK WIRE BLU/BLK WIRE BLU/BRN WIRE BRN WIRE BRN/RED WIRE CD CHANGER COMPUTER DATA LINES SYSTEM DIVERSITY GENERAL MODULE GRY/RED WIRE MULTI-INFORMATION DISPLAY (MID) NAVIGATION CONTROL MODULE NCA WIRE ON BOARD MONITOR REAR WINDOW RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE ROOF SPOILER AERIAL TV AMPLIFIER VIDEO MODULE (IF EQUIPPED) VIO/WHT WIRE W/ 2002 W/ 2003-06 WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRY/YEL WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Premium radio circuit, with top hifi radio (3 of 3) -> NCA WIRE

Wiring diagram nca (40 of 52)

Wiring diagram nca for BMW X5 E53 facelift (2003-2007) (40 of 52)

Get lifetime access to BMW X5 E53 facelift (2003-2007)

BLK WIRE BRN WIRE FUSE FUSE HOLDER GRN WIRE GRN/WHT WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN RUN OR START LEFT REAR SEAT HEATER LEFT REAR SEAT HEATER SWITCH LEFT REAR SEATBACK HEATER NCA WIRE RED WIRE RIGHT REAR SEAT HEATER RIGHT REAR SEAT HEATER SWITCH RIGHT REAR SEATBACK HEATER TERMINAL 15 UNLOADER RELAY WHT WIRE WHT/BRN WIRE WHT/YEL WIRE YEL WIRE YEL/BRN WIRE

Go to component -> Rear heated seats circuit -> NCA WIRE
