BMW X5 E53 facelift (2003-2007) driver door module Wiring diagram
This page shows the only wiring diagram for the component.driver door module, which is found in the car BMW X5 E53 facelift (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver door module (1 of 1)
BLK/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BRN WIRE
BRN/YEL WIRE
DRIVER DOOR MODULE
FUSE 14
FUSE 60
FUSE HOLDER
GENERAL MODULE 0) OFF 1) CLOSE WINDOW 2) OPEN WINDOW (BEHIND GLOVE BOX)
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW PRESSURE SENSITIVE FINGER GUARD
RED/GRY WIRE
RED/WHT WIRE
Go to component -> Power windows circuit (2 of 3) -> DRIVER DOOR MODULE
