Front heated seats circuit for BMW X5 E53 (1999-2003)
Front heated seats circuit
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM INTERIOR LIGHTS SYSTEM
DRIVER'S SEAT HEATER
DRIVER'S SEATBACK HEATER
FUSE HOLDER
GRN WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY/RED WIRE
HOT AT ALL TIMES FUSE
HOT IN RUN, ACCY, OR START FUSE
PASSENGER'S SEAT HEATER
PASSENGER'S SEATBACK HEATER
RED/BLU WIRE
SWITCHING CENTER
VIO WIRE
VIO/BLU WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED/YEL WIRE
YEL WIRE
