Power door locks circuit, early production for BMW X5 E53 (1999-2003)

Power door locks circuit, early production (1 of 3)

X5 BMW E53 (1999-2003): Power door locks circuit, early production (1 of 3)

Get access

ANTENNA AMPLIFIER (WITH REMOTE BLK WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE CENTRAL LOCKING DRIVE, DRIVER'S DOOR CENTRAL LOCKING DRIVE, FRONT PASSENGER'S DOOR CONTROL CENTRAL LOCKING) DRIVER'S DOOR MODULE FUSE 20 FUSE 24 FUSE 73 FUSE 86 FUSE HOLDER GENERAL MODULE HOT AT ALL TIMES PASSENGER'S DOOR MODULE RED/BLK WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE UNLOADER RELAY, TERMINAL R VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/YEL WIRE

Power door locks circuit, early production (2 of 3)

X5 BMW E53 (1999-2003): Power door locks circuit, early production (2 of 3)

Get access

BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/GRY WIRE BRN/WHT WIRE CENTRAL LOCKING DRIVE, REAR LEFT DOOR CENTRAL LOCKING DRIVE, REAR RIGHT DOOR FUEL TANK ACCESS FLAP LOCK MOTOR FUSE 60 FUSE HOLDER GENERAL MODULE GRY/RED WIRE GRY/YEL WIRE HAZARD WARNING FLASHER SWITCH 3) WITH CENTRAL LOCKING FUNCTION HOT AT ALL TIMES LIGHT MODULE RED/WHT WIRE TRUNK LID LOCKING SWITCH 1) UNLOCK 2) LOCK UNDERHOOD LIGHT SWITCH 1) HOOD CLOSED 2) HOOD OPEN VIO/GRN WIRE WHT WIRE YEL/RED WIRE

Power door locks circuit, early production (3 of 3)

X5 BMW E53 (1999-2003): Power door locks circuit, early production (3 of 3)

Get access

ANTI- THEFT HORN BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/YEL WIRE FUSE 13 FUSE 84 FUSE HOLDER FUSE HOLDER GENERAL MODULE GRY/WHT WIRE HOT AT ALL TIMES INTERIOR LIGHTS INTERIOR PROTECTION CONTROL MODULE MOTOR, BOTTOM TAILGATE RED/BLK WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RELAY, BOTTOM TAILGATE MOTOR SWITCH, BOTTOM TAILGATE TILT SENSOR YEL/BLK WIRE YEL/BRN WIRE ZV DRIVE, TOP TAILGATE
