Instrument illumination circuit for BMW X5 E53 (1999-2003)
Instrument illumination circuit
AIR SUSPENSION LEVEL SWITCH
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR MODULE
FRONT ASHTRAY LIGHT
FRONT INTERIOR/ READING LAMP
FUSE
GARAGE DOOR OPENER
GRN/GRY WIRE
GRY/RED WIRE
HAZARD WARNING FLASHER SWITCH
HEATING AND A/C CONTROL MODULE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE HOLDER FUSE
HOT IN RUN OR START
INSTRUMENT CLUSTER
LEFT REAR COMPARTMENT BACKREST ADJUSTMENT SWITCH
LEFT REAR POWER WINDOW SWITCH
LEFT REAR SEAT HEATER SWITCH
LIGHT MODULE
MAYDAY SWITCH
MULTI-INFORMATION DISPLAY
ON BOARD MONITOR
PASSENGER'S DOOR MODULE
RADIO
REAR ASHTRAY LIGHT
REAR COMPARTMENT BLOWER
REAR INTERIOR/ READING LIGHT
RED WIRE
RIGHT REAR COMPARTMENT BACKREST ADJUSTMENT SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR SEAT HEATER SWITCH
SEARCH BUTTON
SUNROOF SWITCH (IF EQUIPPED)
SWITCHING CENTER
TRANSMISSION RANGE INDICATOR LIGHT
W/ IKE W/O IKE W/ ON-BOARD MONITOR W/O ON-BOARD MONITOR 2 3 4
WHT/GRY/YEL WIRE
