BMW X5 E53 (1999-2003) underhood light switch Wiring diagram
This page shows the only wiring diagram for the component.underhood light switch, which is found in the car BMW X5 E53 (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram underhood light switch (1 of 1)
BRN WIRE
CHARGING SOCKET
ELECTRIC FAN
ELECTRIC FUEL PUMP
ENTRY LIGHT MODULE
FINAL STAGE UNIT
FRONT PASSENGER'S SEAT ADJUSTMENT SWITCH
GENERAL MODULE
HEADLIGHT WASHER PUMP
HEATING, A/C CONTROL MODULE
LEFT LICENSE PLATE LIGHT
LEFT REAR SEAT HEATER
LEFT WASHER JET HEATER
PARK HEATING METERING PUMP
PASSENGER'S DOOR ACCESS LIGHT
PASSENGER'S DOOR CENTRAL LOCKING DRIVE
PASSENGER'S DOOR MODULE
PASSENGER'S MAKE-UP MIRROR SWITCH
PASSENGER'S SEAT HEATER
PASSENGER'S SEATBACK HEATER
PASSENGER'S SIDE GLOVE FOOTWELL BOX LIGHT LIGHT
PASSENGER'S SIDE PRESSURE- SENSITIVE FINGER GUARD
POLARITY REVERSAL PROTECTION RELAY
RADAR WARNING SOCKET
RIGHT FOG LIGHT
RIGHT FRONT AUXILIARY RIGHT LOWBEAM
RIGHT FRONT DOOR OPENER LIGHTING
RIGHT HIGHBEAM
RIGHT LICENSE PLATE LIGHT
RIGHT OUTSIDE MIRROR FRONT ZONE LIGHTING
RIGHT REAR ACCESS LIGHT
RIGHT REAR DOOR CENTRAL LOCKING DRIVE
RIGHT REAR DOOR OPENER LIGHTING
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR SEAT HEATER
RIGHT REAR WINDOW PRESSURE- SENSITIVE FINGER GUARD
RIGHT WASHER JET HEATER
SECONDARY AIR INJECTION PUMP RELAY
SUNROOF MODULE
SWITCHING CENTER
TRUNK LID LOCKING SWITCH
UNDERHOOD LIGHT SWITCH
WIPER RELAY
Go to component -> Ground distribution circuit (2 of 5) -> UNDERHOOD LIGHT SWITCH
