BMW X5 E53 (1999-2003) transmission range indicator switch Wiring diagram
This page shows the only wiring diagram for the component.transmission range indicator switch, which is found in the car BMW X5 E53 (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission range indicator switch (1 of 1)
ANTI- THEFT HORN
BRAKE LIGHT SWITCH
BRN WIRE
BRN/BLK WIRE
CHIME MODULE
CLOSED -CIRCUIT CURRENT CUT-OFF RELAY
CLUTCH PEDAL POSITION SWITCH
COMBINATION SWITCH
DRIVER'S MAKE-UP MIRROR SWITCH
ELECTRO- CHROMIC REAR VIEW MIRROR
ELECTRONIC IMMOBILIZER CONTROL UNIT
ENGINE COOLANT BRAKE LEVEL FLUID LEVEL SWITCH SWITCH
GARAGE DOOR OPENER
GENERAL MODULE
HAZARD WASHER WARNING FLUID FLASHER LEVEL SWITCH SWITCH
HEADLIGHT WIDENING CONTROL MODULE
INSTRUMENT CLUSTER
INTEGRATED INSTRUMENT CLUSTER CONTROL MODULE
INTERIOR PROTECTION CONTROL RDC CONTROL MODULE MODULE
LIGHT MODULE
NCA WIRE
OBD II SOCKET
PARK HEATING/ VENTILATION SOLENOID VALVE 2
RAIN SENSOR
REAR WASHER PUMP
RIGHT FRONT AUXILIARY TURN LIGHT
RIGHT FRONT TURN SIGNAL LAMP
RIGHT PARKING LIGHT
SEAT LOAD ASSEMBLY
SECONDARY AIR INJECTION PUMP
SHIFT- LOCK SWITCH
STEERING ANGLE SENSOR
STEERING COLUMN POSITION SWITCH
STEPTRONIC SWITCH
TRANSMISSION RANGE INDICATOR SWITCH
WASHER PUMP
WATER VALVE ASSEMBLY
WIPER/ WASHER SWITCH
Go to component -> Ground distribution circuit (4 of 5) -> TRANSMISSION RANGE INDICATOR SWITCH
