BMW X5 E53 (1999-2003) trailer transfer module case control module Wiring diagram
This page shows the only wiring diagram for the component.trailer transfer module case control module, which is found in the car BMW X5 E53 (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trailer transfer module case control module (1 of 1)
2001 LATE PRODUCTION THRU 2006 2001 ONLY 2004-06 2001-05 2006 2 3 4 5
AIR SUSPENSION COMPRESSOR RELAY OUTPUT STAGE, REAR COMPT BLOWER
AIRBAG TRANSMISSION INDICATOR RANGE LIGHT INDICATOR LIGHT
B+ JUMP
BATTERY
BLK WIRE
BLU WIRE
BRN WIRE
CHARGING SWITCHING SOCKET CENTER
CLUTCH PEDAL POSITION SWITCH (2001) CLUTCH SWITCH MODULE (2002-06)
COIL
COIL SPRING
ELECTRONIC IMMOBILIZER CONTROL UNIT
FUSE
FUSE FUSE
FUSE HOLDER
GENERAL MODULE
GENERATOR
GRN WIRE
GRY WIRE
HORN RELAY (BEHIND GLOVE BOX)
IGNITION SWITCH 0) OFF 1) ACCY 2) RUN 3) START
JUNCTION POINT
LIGHT BRAKE SPRING MODULE LIGHT SWITCH
MAIN FUSE HOLDER
POLARITY REVERSAL PROTECTION RELAY
REAR RAIN INTERMITTENT SENSOR WIPE/WASH (2002-06) CONTROL UNIT
RED WIRE
RED/BLU WIRE
SHIFT- ELECTRONIC LOCK IMMOBILIZER SWITCH CONTROL UNIT (2001)
STARTER
TO FUSE
TRAILER MODULE (2002-06)
TRAILER TRANSFER MODULE CASE CONTROL MODULE
UNLOADER RELAY, TERMINAL R
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> 3.0l, power distribution circuit (1 of 6) -> TRAILER TRANSFER MODULE CASE CONTROL MODULE
