BMW X5 E53 (1999-2003) steering column position switch Wiring diagrams
This page contains all the electrical diagrams for the component. steering column position switch, in which he is found in the car BMW X5 E53 (1999-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram steering column position switch (1 of 2)
ANTI- THEFT HORN
BRAKE LIGHT SWITCH
BRN WIRE
BRN/BLK WIRE
CHIME MODULE
CLOSED -CIRCUIT CURRENT CUT-OFF RELAY
CLUTCH PEDAL POSITION SWITCH
COMBINATION SWITCH
DRIVER'S MAKE-UP MIRROR SWITCH
ELECTRO- CHROMIC REAR VIEW MIRROR
ELECTRONIC IMMOBILIZER CONTROL UNIT
ENGINE COOLANT BRAKE LEVEL FLUID LEVEL SWITCH SWITCH
GARAGE DOOR OPENER
GENERAL MODULE
HAZARD WASHER WARNING FLUID FLASHER LEVEL SWITCH SWITCH
HEADLIGHT WIDENING CONTROL MODULE
INSTRUMENT CLUSTER
INTEGRATED INSTRUMENT CLUSTER CONTROL MODULE
INTERIOR PROTECTION CONTROL RDC CONTROL MODULE MODULE
LIGHT MODULE
NCA WIRE
OBD II SOCKET
PARK HEATING/ VENTILATION SOLENOID VALVE 2
RAIN SENSOR
REAR WASHER PUMP
RIGHT FRONT AUXILIARY TURN LIGHT
RIGHT FRONT TURN SIGNAL LAMP
RIGHT PARKING LIGHT
SEAT LOAD ASSEMBLY
SECONDARY AIR INJECTION PUMP
SHIFT- LOCK SWITCH
STEERING ANGLE SENSOR
STEERING COLUMN POSITION SWITCH
STEPTRONIC SWITCH
TRANSMISSION RANGE INDICATOR SWITCH
WASHER PUMP
WATER VALVE ASSEMBLY
WIPER/ WASHER SWITCH
Go to component -> Ground distribution circuit (4 of 5) -> STEERING COLUMN POSITION SWITCH
Wiring diagram steering column position switch (2 of 2)
ANGLE ADJUST
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/WHT WIRE
CLOSED -CIRCUIT CURRENT CUT-OFF RELAY
COMPUTER DATA LINES SYSTEM
FRT BCK DN UP
FUSE HOLDER
HOT AT ALL TIMES FUSE
LENGTH ADJUST
MEMORY SYSTEM (DRIVER'S MEMORY SEAT CIRCUIT)
NCA WIRE
RED/BRN WIRE
SEAT/STEERING COLUMN MEMORY CONTROL MODULE
STEERING COLUMN ANGLE ADJUST MOTOR
STEERING COLUMN LENGTH ADJUST MOTOR
STEERING COLUMN POSITION SWITCH
WHT/RED/YEL WIRE
Go to component -> Steering column memory circuit -> STEERING COLUMN POSITION SWITCH
