BMW X5 E53 (1999-2003) power distribution system Wiring diagram
This page shows the only wiring diagram for the component.power distribution system, which is found in the car BMW X5 E53 (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power distribution system (1 of 1)
BLK WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
ELECTRONIC IMMOBILIZER CONTROL UNIT (EWS)
ENGINE CONTROL MODULE (DME)
FUSE
FUSE HOLDER
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE HOLDER FUSE
HOT W/ RETAINED ACCESSORY POWER
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/YEL WIRE
RING COIL
STARTING/ CHARGING SYSTEM
STARTING/CHARGING SYSTEM
TRANSMISSION CONTROL UNIT
VIO WIRE
VIO/BLK WIRE
WHT/RED/YEL WIRE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
Go to component -> 4.4l, immobilizer circuit -> POWER DISTRIBUTION SYSTEM
