BMW X5 E53 (1999-2003) length adjust Wiring diagram
This page shows the only wiring diagram for the component.length adjust, which is found in the car BMW X5 E53 (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram length adjust (1 of 1)
ANGLE ADJUST
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/WHT WIRE
CLOSED -CIRCUIT CURRENT CUT-OFF RELAY
COMPUTER DATA LINES SYSTEM
FRT BCK DN UP
FUSE HOLDER
HOT AT ALL TIMES FUSE
LENGTH ADJUST
MEMORY SYSTEM (DRIVER'S MEMORY SEAT CIRCUIT)
NCA WIRE
RED/BRN WIRE
SEAT/STEERING COLUMN MEMORY CONTROL MODULE
STEERING COLUMN ANGLE ADJUST MOTOR
STEERING COLUMN LENGTH ADJUST MOTOR
STEERING COLUMN POSITION SWITCH
WHT/RED/YEL WIRE
Go to component -> Steering column memory circuit -> LENGTH ADJUST
