BMW X5 E53 (1999-2003) dual temperature sensor 1) temperature Wiring diagram
This page shows the only wiring diagram for the component.dual temperature sensor 1) temperature, which is found in the car BMW X5 E53 (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dual temperature sensor 1) temperature (1 of 1)
BLK/GRN WIRE
BLK/GRY WIRE
BLU/GRY WIRE
BRN WIRE
BRN/ORG WIRE
BRN/VIO WIRE
BRN/YEL WIRE
COOLANT OUTLET TEMPERATURE SENSOR
DUAL TEMPERATURE SENSOR 1) TEMPERATURE
ELECTRIC FAN
ENGINE CONTROL MODULE (DME)
FUSE 61
FUSE HOLDER
HOT AT ALL TIMES
INTEGRATED INSTRUMENT CLUSTER CONTROL MODULE (IKE)
RED/BLU WIRE
SENSOR DME 2) REMOTE THERMOMETER
YEL/GRN WIRE
Go to component -> Cooling fan circuit -> DUAL TEMPERATURE SENSOR 1) TEMPERATURE
