BMW X5 E53 (1999-2003) digital motor electronics control unit Wiring diagram
This page shows the only wiring diagram for the component.digital motor electronics control unit, which is found in the car BMW X5 E53 (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram digital motor electronics control unit (1 of 1)
BATTERY
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BRN WIRE
DIGITAL MOTOR ELECTRONICS CONTROL UNIT
ELECTRONIC IMMOBILIZER CONTROL UNIT
GEARSHIFT LOCK (M/T)
GENERATOR
HOT AT ALL TIMES FUSE HOLDER FUSE
IGNITION SWITCH
INSTRUMENT CLUSTER
INTEGRATED INSTRUMENT CLUSTER CONTROL MODULE
OFF
RED WIRE
RUN WIRE
STARTER
TRANSMISSION CONTROL (A/T)
W/ IKE
W/O IKE
Go to component -> 3.0l, starting circuit -> DIGITAL MOTOR ELECTRONICS CONTROL UNIT
