Backup lamps circuit for BMW X5 M F95 facelift (2023-2024)
Backup lamps circuit
BLK WIRE
BLU/YEL WIRE
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN WIRE
CENTER CONSOLE CONTROL
COMPUTER DATA LINES SYSTEM
ELECTRONIC TRANSMISSION CONTROL
FUSE 504
FUSE BOX
GEAR SELECTOR SWITCH
GRY/GRN WIRE
HOT AT ALL TIMES
LEFT OUTER TAIL LIGHT
RED WIRE
REVERSING LIGHT
RIGHT OUTER TAIL LIGHT
WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
