BMW X5 M F95 facelift (2023-2024) w/ third seat row Wiring diagram
This page shows the only wiring diagram for the component.w/ third seat row, which is found in the car BMW X5 M F95 facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ third seat row (1 of 1)
BLK/GRY WIRE
BLU/GRN WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BRN WIRE
DRIVER BELT FORCE LIMITER GAS GENERATOR
FRONT PASSENGER ACTIVE HEAD RESTRAINT GAS GENERATOR
FRONT PASSENGER BELT FORCE LIMITER GAS GENERATOR
FRONT PASSENGER RETRACTOR TENSIONER
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/BLK WIRE
GRY/BRN WIRE
LEFT "C" PILLAR)
LEFT REAR RETRACTOR TENSIONER
LEFT REAR SIDE AIR BAG GAS GENERATOR
LEFT THIRD ROW SEAT BELT BUCKLE CONTACT
ORG/ WIRE
ORG/YEL WIRE
REAR CENTER SEAT BELT BUCKLE CONTACT
REAR DRIVER'S SIDE SEAT BELT BUCKLE CONTACT
REAR PASSENGER'S SIDE BELT BUCKLE CONTACT
RIGHT REAR RETRACTOR TENSIONER
RIGHT REAR SIDE AIR BAG GAS GENERATOR
W/ SEAT MODULE
W/ THIRD SEAT ROW
WHT/BLK WIRE
WHT/BRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (3 of 4) -> W/ THIRD SEAT ROW
