BMW X5 M F95 facelift (2023-2024) right rear near rear radar sensor Wiring diagram
This page shows the only wiring diagram for the component.right rear near rear radar sensor, which is found in the car BMW X5 M F95 facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear near rear radar sensor (1 of 1)
3.0L TURBO HYBRID
AIR CONDITIONING COMPRESSOR
ANTI SLIP RAILS CONTROL ELECTRONICS
AUXILIARY BATTERY
BODY DOMAIN CONTROLLER
BOOSTER
BRN WIRE
BRN/BLK WIRE
CAN BUS TERMINAL RESISTOR 11
CAN BUS TERMINAL RESISTOR 6
CRASH SAFETY MODULE
DIGITAL MOTOR ELECTRONICS 2
DRIVER'S SEAT BELT BUCKLE CONTACT
ELECTRIC AUXILIARY HEATER
ELECTRICAL EXHAUST FLAP 2
FRONT PASSENGER SEAT OCCUPANCY DETECTION EVALUATION ELECTRONICS
FRONT PASSENGER SEAT POSITION SENSOR
FRONT PASSENGER'S SEAT BELT BUCKLE CONTACT
HEAD UNIT
HIGH-VOLTAGE CHARGING SOCKET
INFOTAINMENT FAN
LEFT "C" PILLAR)
LEFT REAR NEAR RANGE RADAR SENSOR
LEFT REAR SHORT RANGE RADAR SENSOR (HRSNL)
LEFT THIRD ROW SEAT BELT BUCKLE CONTACT
NCA WIRE
POWER CONTROL UNIT
REAR CENTER SEAT BELT BUCKLE CONTACT
REAR DRIVER'S SIDE SEAT BELT BUCKLE CONTACT
REAR PASSENGER'S SIDE SEAT BELT BUCKLE CONTACT
REGULATED DIFFERENTIAL LOCK
RETRACTABLE ROLLER COVER LUGGAGE COMPARTMENT CONTROL ELECTRONICS
RIGHT LOWER TRUNK LID LOCK
RIGHT REAR NEAR REAR RADAR SENSOR
RIGHT REAR SHORT RANGE RADAR SENSOR (HRSNR)
RIGHT SOFT-CLOSE AUTOMATIC LOWER TRUNK LID
RIGHT THIRD ROW SEAT BELT BUCKLE CONTACT
TRAILER MODULE
TRAILER SOCKET
USB PORT 2
W/ SEAT MODULE
WIRELESS CHARGING SHELF ANTENNA AMPLIFIER
YEL/GRN WIRE
Go to component -> Ground distribution circuit (2 of 7) -> RIGHT REAR NEAR REAR RADAR SENSOR
