BMW X5 M F95 facelift (2023-2024) rear driver's seat backrest panel lighting Wiring diagram
This page shows the only wiring diagram for the component.rear driver's seat backrest panel lighting, which is found in the car BMW X5 M F95 facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear driver's seat backrest panel lighting (1 of 1)
BLK/GRN WIRE
BLU WIRE
BLU/WHT WIRE
BOTTOM CENTER DASHBOARD LIGHTING
BOTTOM DRIVER'S SIDE DASHBOARD LIGHTING
BOTTOM FRONT PASSENGER'S SIDE DASHBOARD LIGHTING
CENTER CONSOLE LIGHTING
CENTER CONSOLE LIGHTING 2
GRN WIRE
GRN/BLK WIRE
GRY/GRN WIRE
GRY/VIO WIRE
LEFT FRONT GLASS SUNROOF LIGHTING
LEFT FRONT REAR GLASS SUNROOF LIGHTING
LEFT REAR GLASS SUNROOF LIGHTING
REAR DRIVER'S SEAT BACKREST PANEL LIGHTING
REAR DRIVER'S SIDE FOOTWELL LIGHT
REAR FRONT PASSENGER SEAT BACKREST PANEL LIGHTING
REAR PASSENGER'S SIDE FOOTWELL LIGHT
RIGHT FRONT FOOTWELL LIGHT
RIGHT FRONT GLASS SUNROOF LIGHTING
RIGHT FRONT REAR GLASS SUNROOF LIGHTING
RIGHT REAR GLASS SUNROOF LIGHTING
TOP CENTER DASHBOARD LIGHTING
TOP FRONT PASSENGER'S SIDE DASHBOARD LIGHTING
VIO/YEL WIRE
WHT WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> High/low bus circuit (7 of 10) -> REAR DRIVER'S SEAT BACKREST PANEL LIGHTING
