BMW X5 M F95 facelift (2023-2024) left rear center ultrasonic sensor Wiring diagrams

This page contains all the electrical diagrams for the component. left rear center ultrasonic sensor, in which he is found in the car BMW X5 M F95 facelift (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram left rear center ultrasonic sensor (1 of 3)

Wiring diagram left rear center ultrasonic sensor for BMW X5 M F95 facelift (2023-2024) (1 of 3)

Get access

BRN WIRE BRN/ORG WIRE BRN/RED WIRE CENTER CONSOLE CONTROL COMPUTER DATA LINES SYSTEM FUSE 32 GRN/GRY WIRE HOT AT ALL TIMES LEFT REAR CENTER ULTRASONIC SENSOR LEFT REAR OUTER ULTRASONIC SENSOR LEFT REAR ULTRASONIC SENSOR ORG/ WIRE ORG/GRN WIRE PARKING ASSISTANCE BUTTON RED/BLU WIRE RED/YEL WIRE RIGHT FRONT POWER DISTRIBUTION BOX RIGHT REAR CENTER ULTRASONIC SENSOR RIGHT REAR OUTER ULTRASONIC SENSOR RIGHT REAR ULTRASONIC SENSOR WHT/BLU WIRE WHT/YEL WIRE YEL/BRN WIRE

Go to component -> Parking assistant circuit, w/o parking maneuvering assistant & surround view camera (2 of 2) -> LEFT REAR CENTER ULTRASONIC SENSOR

Wiring diagram left rear center ultrasonic sensor (2 of 3)

Wiring diagram left rear center ultrasonic sensor for BMW X5 M F95 facelift (2023-2024) (2 of 3)

Get access

BRN WIRE BRN/ORG WIRE BRN/RED WIRE CENTER CONSOLE CONTROL COMPUTER DATA LINES SYSTEM FRONT AUTONOMOUS PARKING CAMERA FUSE 32 GRN/GRY WIRE HOT AT ALL TIMES LEFT AUTONOMOUS PARKING CAMERA LEFT REAR CENTER ULTRASONIC SENSOR LEFT REAR OUTER ULTRASONIC SENSOR LEFT REAR ULTRASONIC SENSOR NCA WIRE ORG/ WIRE ORG/GRN WIRE PARKING ASSISTANCE BUTTON REAR AUTONOMOUS PARKING CAMERA RED/BLU WIRE RED/YEL WIRE RIGHT AUTONOMOUS PARKING CAMERA RIGHT FRONT POWER DISTRIBUTION BOX RIGHT REAR CENTER ULTRASONIC SENSOR RIGHT REAR OUTER ULTRASONIC SENSOR RIGHT REAR ULTRASONIC SENSOR WHT WIRE WHT/BLU WIRE WHT/YEL WIRE YEL/BRN WIRE

Go to component -> Parking assistant circuit, w/o parking maneuvering assistant & w/ surround view camera (2 of 2) -> LEFT REAR CENTER ULTRASONIC SENSOR
