BMW X5 M F95 facelift (2023-2024) driver's side rear seat backrest folding down switch Wiring diagram
This page shows the only wiring diagram for the component.driver's side rear seat backrest folding down switch, which is found in the car BMW X5 M F95 facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's side rear seat backrest folding down switch (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SEAT SWITCH CLUSTER
DRIVER'S SIDE REAR SEAT BACKREST FOLDING DOWN SWITCH
GRN WIRE
GRN/BLK WIRE
GRY/WHT WIRE
HALL EFFECT SENSOR
LEFT SEAT BENCH MICROSWITCH
LEFT SEAT BENCH MICROSWITCH 2
REAR DRIVER'S SIDE CONVENIENT ENTRY SWITCH
REAR DRIVER'S SIDE FORWARD/ BACK SEAT ADJUSTMENT DRIVE
REAR DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
REAR DRIVER'S SIDE SEAT MODULE
RED/BLK WIRE
RED/GRN WIRE
SEATS SYSTEM
SERVOMOTOR
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Left memory rear seat circuit (2 of 2) -> DRIVER'S SIDE REAR SEAT BACKREST FOLDING DOWN SWITCH
