BMW X5 M F95 facelift (2023-2024) driver side seat adjustment switch block Wiring diagram
This page shows the only wiring diagram for the component.driver side seat adjustment switch block, which is found in the car BMW X5 M F95 facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side seat adjustment switch block (1 of 1)
3.0L TURBO HYBRID
AIR FRESHENER
AUTOMATIC TRANSMISSION
BLU/VIO WIRE
BRN WIRE
CD DRIVE
CLOSE RANGE RADAR SENSOR CONTROL UNIT (RSNECU)
COMPUTER DATA LINES SYSTEM
DASH BOARD LOUDSPEAKER LIGHTING
DISPLAY GROUP
DRIVER SEAT MODULE
DRIVER SIDE SEAT ADJUSTMENT SWITCH BLOCK
DRIVER'S SIDE CONTROL ELECTRONICS ARMREST HEATING
ELECTRICAL STEERING COLUMN ADJUSTMENT
ELECTROCHROMIC INTERIOR MIRROR
ELECTRONIC TRANSMISSION CONTROL
FROM FUSE BOX (DIAGRAM 2 OF 10)
FROM RIGHT DISTRIBUTION BOX FRONT POWER (DIAGRAM 5 OF 10)
FRONT PASSENGER SEAT MODULE
FRONT PASSENGER'S SIDE CONTROL ELECTRONICS ARMREST HEATING
FUSE 37
FUSE 46
FUSE 47
FUSE 49
FUSE 50
FUSE 51
FUSE 53
FUSE 54
FUSE 55
FUSE 56
FUSE 57
FUSE 59
FUSE 63
FUSE 73
GRY/YEL WIRE
INDEPENDENT AUXILIARY HEATER
INSTRUMENT PANEL
IONIZER
LIN POWER DISTRIBUTION BOX
NCA WIRE
PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK
REAR COMPARTMENT BLOWER MOTOR OUTPUT STAGE
REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/BRN YEL) WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
THERMOELECTRIC CUP HOLDER
TO AUXILIARY BATTERY (W/ DUAL STORAGE SYSTEM) (DIAGRAM 1 OF 10)
TO FUSE 24 (DIAGRAM 2 OF 10)
TO FUSE 60 (DIAGRAM 4 OF 10)
TO FUSE 64 (DIAGRAM 10 OF 10)
TRANSFER BOX
USB PORT 2
VIO WIRE
W/ THERMOELECTRIC CUP HOLDER W/O THERMOELECTRIC CUP HOLDER W/ MEMORY
W/O MEMORY
WHT/BRN WIRE
WIPER MODULE
YEL/GRN WIRE
Go to component -> Power distribution circuit (3 of 10) -> DRIVER SIDE SEAT ADJUSTMENT SWITCH BLOCK
