BMW X5 M F95 facelift (2023-2024) brn Wiring diagrams
This page contains all the electrical diagrams for the component. brn, in which he is found in the car BMW X5 M F95 facelift (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram brn (51 of 173)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BRN WIRE
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR ARMREST HEATING
DRIVER'S SIDE CONTROL ELECTRONICS FOR ARMREST HEATING
DRIVER'S SIDE MIDDLE CONSOLE ARMREST HEATING
FRONT PASSENGER'S DOOR ARMREST HEATING
FRONT PASSENGER'S SIDE CONTROL ELECTRONICS FOR ARMREST HEATING
FRONT PASSENGER'S SIDE MIDDLE CONSOLE ARMREST HEATING
FUSE 56
FUSE 57
GRN WIRE
HOT W/ TERMINAL
NCA WIRE
ORG/ WIRE
ORG/GRN WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT POWER DISTRIBUTION BOX
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Front armrest heating circuit -> BRN WIRE
Wiring diagram brn (52 of 173)
AIR CONDITIONING
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRASH SAFETY MODULE
DRIVER THIGH SUPPORT HEATING
DRIVER'S SEAT BACKREST HEATING
DRIVER'S SEAT HEATING ELECTRONICS
DRIVER'S SEAT SURFACE HEATING
FRONT PASSENGER SEAT HEATING ELECTRONICS
FRONT PASSENGER SEAT OCCUPANCY DETECTION EVALUATION ELECTRONICS
FRONT PASSENGER SEAT OCCUPANCY DETECTION SEAT CUSHION HEATER/SENSOR
FRONT PASSENGER THIGH SUPPORT HEATING
FRONT PASSENGER'S SEAT BACKREST HEATING
FUSE 48
FUSE 52
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRY/YEL WIRE
NCA WIRE
ORG/GRN WIRE
RED WIRE
RED/GRN WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
W/ EXTENDABLE THIGH SUPPORT
W/O EXTENDABLE THIGH SUPPORT
YEL WIRE
Go to component -> Front heated seats circuit, w/o memory -> BRN WIRE
Wiring diagram brn (53 of 173)
BLK WIRE
BLU WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRONICS TOUCH DETECTION
FUSE 74
GRN WIRE
GRN/BLU WIRE
GRY/BLK WIRE
HEATED STEERING WHEEL FUNCTION INDICATOR LIGHT
INSTRUMENT PANEL
NCA WIRE
RED WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
SPORT BUTTON
STEERING COLUMN SWITCH CLUSTER
STEERING WHEEL HEATED SWITCH
STEERING WHEEL HEATING
STEERING WHEEL MODULE (RIGHT CENTER OF STEERING WHEEL)
VIBRATION ACTUATOR
WHT/GRY WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Heated steering wheel circuit -> BRN WIRE
Wiring diagram brn (54 of 173)
BRN WIRE
BRN/ORG WIRE
DRIVER LUMBAR SUPPORT VALVE BLOCK
DRIVER'S SEAT PNEUMATIC PUMP
DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
FRONT PASSENGER SEAT PNEUMATIC PUMP
FRONT PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK
FUSE 64
FUSE 65
RED WIRE
RED/BLK WIRE
RED/GRY WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
SPORT SEATS CIRCUIT
VIO WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Lumbar circuit -> BRN WIRE
Wiring diagram brn (55 of 173)
BLK WIRE
BLU WIRE
BRN WIRE
FRONT PASSENGER SEAT ANGLE ADJUSTMENT DRIVE
FRONT PASSENGER SEAT BACKREST ANGLE ADJUSTMENT DRIVE
FRONT PASSENGER SEAT FORWARD/ BACK SEAT ADJUSTMENT
FRONT PASSENGER SEAT HEADREST HEIGHT ADJUSTMENT DRIVE
FRONT PASSENGER SEAT HEIGHT ADJUSTMENT DRIVE
FUSE 55
GRN WIRE
GRY WIRE
PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK
RED WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
WHT WIRE
YEL WIRE
Go to component -> Passenger power seat circuit -> BRN WIRE
Wiring diagram brn (56 of 173)
BRN WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SEAT SWITCH CLUSTER
DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
FUSE 64
FUSE 65
FUSE 67
FUSE 68
HOT W/
LEFT FRONT SEAT PNEUMATICS MODULE
LEFT FRONT SEAT PNEUMATICS MODULE PUMP
NCA WIRE
PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK
PASSENGER'S DOOR SEAT SWITCH CLUSTER
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT FRONT SEAT PNEUMATICS MODULE
RIGHT FRONT SEAT PNEUMATICS MODULE PUMP
WHT WIRE
WHT/YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Pneumatics seat circuit -> BRN WIRE
Wiring diagram brn (57 of 173)
AIR CONDITIONING
AUTOMATIC REAR AIR CONDITIONING OPERATING FACILITY
BLK/BRN WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 253
FUSE 269
FUSE 271
GRN WIRE
HOT W/
LEFT REAR SEAT HEATING SWITCH
NCA WIRE
ORG/GRN WIRE
REAR DRIVER'S SIDE BACKREST HEATING
REAR DRIVER'S SIDE SEAT CUSHION HEATING
REAR DRIVER'S SIDE SEAT MODULE
REAR FRONT PASSENGER SIDE SEAT MODULE
REAR PASSENGER'S SIDE BACKREST HEATING
REAR PASSENGER'S SIDE SEAT CUSHION HEATER
REAR POWER DISTRIBUTION BOX
RED/BLK WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT REAR SEAT HEATING SWITCH
VIO/GRY WIRE
W/ OPTIONAL EQUIPMENT
W/O OPTIONAL EQUIPMENT
WHT/GRN WIRE
YEL WIRE
YEL/BRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Rear heated seats circuit, w/ memory -> BRN WIRE
Wiring diagram brn (58 of 173)
AIR CONDITIONING
AUTOMATIC REAR AIR CONDITIONING OPERATING FACILITY
BLU WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 253
FUSE 271
GRN WIRE
HOT W/
LEFT REAR SEAT HEATING SWITCH
NCA WIRE
ORG/GRN WIRE
REAR DRIVER'S SIDE BACKREST HEATING
REAR DRIVER'S SIDE SEAT CUSHION HEATING
REAR DRIVER'S SIDE SEAT HEATING MODULE
REAR PASSENGER'S SIDE BACKREST HEATING
REAR PASSENGER'S SIDE SEAT CUSHION HEATER
REAR PASSENGER'S SIDE SEAT HEATING MODULE
REAR POWER DISTRIBUTION BOX
RED/GRN WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT REAR SEAT HEATING SWITCH
VIO/GRY WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Rear heated seats circuit, w/o memory -> BRN WIRE
Wiring diagram brn (59 of 173)
AIR CONDITIONING
BRN WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
FRONT PASSENGER SEAT MODULE
FRONT PASSENGER'S SEAT CUSHION FAN 1
FRONT PASSENGER'S SEAT CUSHION FAN 2
FRONT PASSENGER'S SEAT CUSHION FAN 3
FRONT PASSENGER'S SEAT CUSHION FAN 4
GRN WIRE
ORG/GRN WIRE
PASSENGER'S SEAT BACKREST FAN 1
PASSENGER'S SEAT BACKREST FAN 2
PASSENGER'S SEAT BACKREST FAN 3
PASSENGER'S SEAT BACKREST FAN 4
RED/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Seat ventilation circuit (2 of 2) -> BRN WIRE
Wiring diagram brn (60 of 173)
BLK WIRE
BRN WIRE
DRIVER LUMBAR SUPPORT VALVE BLOCK
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
DRIVER'S SEAT PNEUMATIC PUMP
DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
FRONT PASSENGER SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
FRONT PASSENGER SEAT PNEUMATIC PUMP
FRONT RIGHT POWER DISTRIBUTION BOX
FUSE 64
FUSE 65
GRN WIRE
HOT W/ TERMINAL
PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
RED WIRE
RED/BLK WIRE
RED/GRY WIRE
RED/YEL WIRE
VIO WIRE
W/ LUMBAR SUPPORT
W/ SEAT MODULE
W/O LUMBAR SUPPORT
W/O SEAT MODULE
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Sport seats circuit -> BRN WIRE
