BMW X5 M F95 facelift (2023-2024) auxiliary control unit Wiring diagram
This page shows the only wiring diagram for the component.auxiliary control unit, which is found in the car BMW X5 M F95 facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auxiliary control unit (1 of 1)
AUXILIARY CONTROL UNIT
BLK/GRN WIRE
BRN WIRE
CAN BUS TERMINAL RESISTOR 2 (RIGHT FRONT SIDE OF LUGGAGE COMPT)
CONTROLLER (IDRIVE)
DRIVER'S SEAT HEATING ELECTRONICS
DRIVER'S SIDE CONTROL ELECTRONICS ARMREST HEATING
FRONT PASSENGER SEAT MODULE
FRONT PASSENGER'S SEAT HEATING ELECTRONICS
FRONT PASSENGER'S SIDE CONTROL ELECTRONICS ARMREST HEATING
GRN WIRE
GRN/BLK WIRE
GRY/GRN WIRE
GRY/VIO WIRE
LEFT REAR SEAT HEATING SWITCH
ORG/GRN WIRE
REAR DRIVER'S SIDE SEAT HEATING MODULE
REAR PASSENGER'S SIDE SEAT HEATING MODULE
RIGHT FRONT SEAT PNEUMATICS MODULE
RIGHT REAR SEAT HEATING SWITCH
ROOF FUNCTION CENTER
VIO/YEL WIRE
WHT WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> High/low bus circuit (6 of 10) -> AUXILIARY CONTROL UNIT
