BMW X5 M F95 facelift (2023-2024) amplifier signal antenna 2 Wiring diagrams
This page contains all the electrical diagrams for the component. amplifier signal antenna 2, in which he is found in the car BMW X5 M F95 facelift (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram amplifier signal antenna 2 (1 of 6)
ACOUSTIC PEDESTRIAN PROTECTION SPEAKER
ACOUSTIC PEDESTRIAN PROTECTION SPEAKER 2
AM ANTENNA
AMPLIFIER ANTENNA
AMPLIFIER SIGNAL ANTENNA 2
BLK WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CARD READER
CENTER FRONT MID-RANGE SPEAKER
CENTER FRONT TWEETER
FM ANTENNA
GRN WIRE
LEFT "C" PILLAR)
LEFT REAR MID-RANGE SPEAKER
NCA WIRE
REAR SPOILER ANTENNA
REAR WINDOW ANTENNA
RECEIVER AUDIO MODULE
RED WIRE
RED/BLU WIRE
RIGHT REAR MID-RANGE SPEAKER
TV ANTENNA 1
VIO/BRN WIRE
VIO/RED WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, base (1 of 5) -> AMPLIFIER SIGNAL ANTENNA 2
Wiring diagram amplifier signal antenna 2 (2 of 6)
AMPLIFIER SIGNAL ANTENNA 2
AMPLIFIER SIGNAL ANTENNA 3
AUDIO CONTROL PANEL
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/WHT WIRE
DAB BAND 3 ANTENNA
DAB BAND 3 ANTENNA 2
FRONT CENTER TWEETER
FUSE 1
GRN WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRY WIRE
GRY/BRN WIRE
HOT W/ BI-STABLE RELAY ENERGIZED
LEFT "C" PILLAR)
LEFT FRONT TWEETER
LEFT REAR TWEETER 2
LEFT SIDE WINDOW ANTENNA
MICROPHONE
MICROPHONE 2 +
NCA WIRE
RED WIRE
RED/YEL WIRE
RIGHT FRONT TWEETER
RIGHT SIDE WINDOW ANTENNA
TV ANTENNA 2
TV ANTENNA 3
VIO/YEL WIRE
W/ TELEMATICS
W/O TELEMATICS
WHT WIRE
WHT/RED WIRE
YEL/BLK WIRE
Go to component -> Navigation circuit, high level (2 of 6) -> AMPLIFIER SIGNAL ANTENNA 2
Wiring diagram amplifier signal antenna 2 (3 of 6)
ACOUSTIC PEDESTRIAN PROTECTION SPEAKER
ACOUSTIC PEDESTRIAN PROTECTION SPEAKER 2
AMPLIFIER SIGNAL ANTENNA 2
AMPLIFIER SIGNAL ANTENNA 3
BLK/BRN WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DAB BAND 3 ANTENNA
DAB BAND 3 ANTENNA 2
LEFT "C" PILLAR)
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT TWEETER
LEFT REAR MID- RANGE SPEAKER 2
LEFT REAR MID-RANGE SPEAKER
LEFT REAR TWEETER
LEFT REAR TWEETER 2
LEFT SIDE WINDOW ANTENNA
NCA WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT TWEETER
RIGHT SIDE WINDOW ANTENNA
TV ANTENNA 2
TV ANTENNA 3
WHT WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, mid level (2 of 5) -> AMPLIFIER SIGNAL ANTENNA 2
Wiring diagram amplifier signal antenna 2 (4 of 6)
ACOUSTIC PEDESTRIAN PROTECTION SPEAKER
ACOUSTIC PEDESTRIAN PROTECTION SPEAKER 2
AM ANTENNA
AMPLIFIER ANTENNA
AMPLIFIER SIGNAL ANTENNA 2
BLK WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CARD READER
CENTER FRONT MID-RANGE SPEAKER
CENTER FRONT TWEETER
FM ANTENNA
GRN WIRE
LEFT "C" PILLAR)
LEFT REAR MID-RANGE SPEAKER
NCA WIRE
REAR SPOILER ANTENNA
REAR WINDOW ANTENNA
RECEIVER AUDIO MODULE
RED WIRE
RED/BLU WIRE
RIGHT REAR MID-RANGE SPEAKER
TV ANTENNA 1
VIO/BRN WIRE
VIO/RED WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Receiver audio module circuit, base (1 of 5) -> AMPLIFIER SIGNAL ANTENNA 2
Wiring diagram amplifier signal antenna 2 (5 of 6)
AMPLIFIER SIGNAL ANTENNA 2
AMPLIFIER SIGNAL ANTENNA 3
AUDIO CONTROL PANEL
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/WHT WIRE
DAB BAND 3 ANTENNA
DAB BAND 3 ANTENNA 2
FRONT CENTER TWEETER
FUSE 1
GRN WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRY WIRE
GRY/BRN WIRE
HOT W/ BI-STABLE RELAY ENERGIZED
LEFT "C" PILLAR)
LEFT FRONT TWEETER
LEFT REAR TWEETER 2
LEFT SIDE WINDOW ANTENNA
MICROPHONE
MICROPHONE 2 +
NCA WIRE
RED WIRE
RED/YEL WIRE
RIGHT FRONT TWEETER
RIGHT SIDE WINDOW ANTENNA
TV ANTENNA 2
TV ANTENNA 3
VIO/YEL WIRE
W/ TELEMATICS
W/O TELEMATICS
WHT WIRE
WHT/RED WIRE
YEL/BLK WIRE
Go to component -> Receiver audio module circuit, high level (2 of 6) -> AMPLIFIER SIGNAL ANTENNA 2
Wiring diagram amplifier signal antenna 2 (6 of 6)
ACOUSTIC PEDESTRIAN PROTECTION SPEAKER
ACOUSTIC PEDESTRIAN PROTECTION SPEAKER 2
AMPLIFIER SIGNAL ANTENNA 2
AMPLIFIER SIGNAL ANTENNA 3
BLK/BRN WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DAB BAND 3 ANTENNA
DAB BAND 3 ANTENNA 2
LEFT "C" PILLAR)
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT TWEETER
LEFT REAR MID- RANGE SPEAKER 2
LEFT REAR MID-RANGE SPEAKER
LEFT REAR TWEETER
LEFT REAR TWEETER 2
LEFT SIDE WINDOW ANTENNA
NCA WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT TWEETER
RIGHT SIDE WINDOW ANTENNA
TV ANTENNA 2
TV ANTENNA 3
WHT WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Receiver audio module circuit, mid level (2 of 5) -> AMPLIFIER SIGNAL ANTENNA 2
