BMW X5 M F95 facelift (2023-2024) acoustic sensor Wiring diagrams
This page contains all the electrical diagrams for the component. acoustic sensor, in which he is found in the car BMW X5 M F95 facelift (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram acoustic sensor (1 of 4)
ACOUSTIC SENSOR
AUDIO CONTROL PANEL
BLU WIRE
BODY DOMAIN CONTROLLER
BOOSTER
BRN WIRE
CENTRAL INFORMATION DISPLAY
COMPUTER DATA LINES SYSTEM
DISPLAY GROUP
DRIVER CAMERA SYSTEM
DRIVER DISPLAY
FUSE 1
FUSE 27
FUSE 73
GRN WIRE
GRN/GRY WIRE
GRN/RED WIRE
HEAD UNIT
HOT AT ALL TIMES
HOT W/
HOT W/ BI-STABLE RELAY ENERGIZED
INSTRUMENT CLUSTER (KOMBI)
LEFT "C" PILLAR)
NCA WIRE
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
VIO/YEL WIRE
W/ DISPLAY GROUP
W/ DRIVER CAMERA SYSTEM
W/O DISPLAY GROUP
W/O DRIVER CAMERA SYSTEM
WHT WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Navigation circuit, base (5 of 5) -> ACOUSTIC SENSOR
Wiring diagram acoustic sensor (2 of 4)
ACOUSTIC SENSOR
BLK/BRN WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRN WIRE
CENTRAL INFORMATION DISPLAY
DISPLAY GROUP
DRIVER CAMERA SYSTEM
DRIVER DISPLAY
FRONT CENTER MID-RANGE SPEAKER
FUSE 27
FUSE 73
GRN WIRE
GRN/GRY WIRE
HEAD UNIT
HOT AT ALL TIMES
HOT W/
INSTRUMENT CLUSTER (KOMBI)
LEFT FRONT BASS SPEAKER
LEFT FRONT MID-RANGE SPEAKER
LEFT REAR MID- RANGE SPEAKER 2
LEFT REAR MID-RANGE SPEAKER
NCA WIRE
ORG/ WIRE
RED/BLK WIRE
RED/GRY WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT REAR MID- RANGE SPEAKER 2
RIGHT REAR MID-RANGE SPEAKER
VIO/BRN WIRE
VIO/RED WIRE
VIO/YEL WIRE
W/ DISPLAY GROUP
W/ DRIVER CAMERA SYSTEM
W/O DISPLAY GROUP
W/O DRIVER CAMERA SYSTEM
WHT WIRE
WHT/BRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, high level (6 of 6) -> ACOUSTIC SENSOR
Wiring diagram acoustic sensor (3 of 4)
ACOUSTIC SENSOR
AUDIO CONTROL PANEL
BLU WIRE
BODY DOMAIN CONTROLLER
BOOSTER
BRN WIRE
CENTRAL INFORMATION DISPLAY
COMPUTER DATA LINES SYSTEM
DISPLAY GROUP
DRIVER CAMERA SYSTEM
DRIVER DISPLAY
FUSE 1
FUSE 27
FUSE 73
GRN WIRE
GRN/GRY WIRE
GRN/RED WIRE
HEAD UNIT
HOT AT ALL TIMES
HOT W/
HOT W/ BI-STABLE RELAY ENERGIZED
INSTRUMENT CLUSTER (KOMBI)
LEFT "C" PILLAR)
NCA WIRE
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
VIO/YEL WIRE
W/ DISPLAY GROUP
W/ DRIVER CAMERA SYSTEM
W/O DISPLAY GROUP
W/O DRIVER CAMERA SYSTEM
WHT WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Receiver audio module circuit, base (5 of 5) -> ACOUSTIC SENSOR
Wiring diagram acoustic sensor (4 of 4)
ACOUSTIC SENSOR
BLK/BRN WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRN WIRE
CENTRAL INFORMATION DISPLAY
DISPLAY GROUP
DRIVER CAMERA SYSTEM
DRIVER DISPLAY
FRONT CENTER MID-RANGE SPEAKER
FUSE 27
FUSE 73
GRN WIRE
GRN/GRY WIRE
HEAD UNIT
HOT AT ALL TIMES
HOT W/
INSTRUMENT CLUSTER (KOMBI)
LEFT FRONT BASS SPEAKER
LEFT FRONT MID-RANGE SPEAKER
LEFT REAR MID- RANGE SPEAKER 2
LEFT REAR MID-RANGE SPEAKER
NCA WIRE
ORG/ WIRE
RED/BLK WIRE
RED/GRY WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT REAR MID- RANGE SPEAKER 2
RIGHT REAR MID-RANGE SPEAKER
VIO/BRN WIRE
VIO/RED WIRE
VIO/YEL WIRE
W/ DISPLAY GROUP
W/ DRIVER CAMERA SYSTEM
W/O DISPLAY GROUP
W/O DRIVER CAMERA SYSTEM
WHT WIRE
WHT/BRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Receiver audio module circuit, high level (6 of 6) -> ACOUSTIC SENSOR
