BMW X5 M F95 (2019-2023) trunk lid tailgate button Wiring diagram
This page shows the only wiring diagram for the component.trunk lid tailgate button, which is found in the car BMW X5 M F95 (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk lid tailgate button (1 of 1)
BLK/GRY WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRONIC SUSPENSION SYSTEM
FRONT RIGHT POWER DISTRIBUTION BOX
FUEL FILLER FLAP CENTRAL LOCKING DRIVE
FUSE 3
FUSE 39
FUSE 67
GRN WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL
HOT W/ TERMINAL 30 BI-STABLE RELAY ENERGIZED
LOWER TRUNK LID TAILGATE BUTTON
NCA WIRE
OUTER TAILGATE LID BUTTON
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT SOFT-CLOSE AUTOMATIC LOWER TRUNK LID
RIGHT TRUNK LID LIFTING DRIVE
TAILGATE LOCK
TRUNK LID POWERTRAIN AUTOMATIC SOFT CLOSE SYSTEM
TRUNK LID TAILGATE BUTTON
VIO/GRY WIRE
WHT WIRE
WHT/BRN WIRE
YEL WIRE
Go to component -> Trunk & fuel door release circuit (2 of 2) -> TRUNK LID TAILGATE BUTTON
