BMW X5 M F95 (2019-2023) rear passenger's side inside door handle light Wiring diagram
This page shows the only wiring diagram for the component.rear passenger's side inside door handle light, which is found in the car BMW X5 M F95 (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear passenger's side inside door handle light (1 of 1)
BLK/GRN WIRE
BLU WIRE
BLU/WHT WIRE
CENTER FRONT PASSENGER DOOR TRIM PANEL LIGHTING
CENTER REAR PASSENGER'S SIDE DOOR TRIM PANEL LIGHTING
DRIVER OUTSIDE DOOR HANDLE ELECTRONICS
DRIVER'S DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
DRIVER'S DOOR SEAT SWITCH CLUSTER
DRIVER'S SIDE REAR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
DRIVER'S SIDE REAR ROLLER SUNBLIND SWITCH BLOCK
FRONT CENTER VENTILATION GRILLE
FRONT INTERIOR LIGHT
FRONT PASSENGER INSIDE DOOR HANDLE LIGHT
FRONT PASSENGER'S DOOR POCKET LIGHTING
GRN WIRE
GRN/BLK WIRE
GRY/GRN WIRE
GRY/VIO WIRE
LEFT REAR INTERIOR LIGHT
LIGHT OPERATING UNIT
RAIN/LIGHT/ SOLAR CONDENSATION SENSOR
REAR INTERIOR LIGHT
REAR PASSENGER'S SIDE DOOR POCKET LIGHTING
REAR PASSENGER'S SIDE INSIDE DOOR HANDLE LIGHT
RIGHT REAR INTERIOR LIGHT
TOP FRONT PASSENGER DOOR TRIM PANEL LIGHTING
TOP REAR PASSENGER'S DOOR TRIM PANEL LIGHTING
VIO/YEL WIRE
W/ PANORAMA GLASS ROOF
W/O PANORAMA GLASS ROOF
WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> High/low bus circuit (9 of 10) -> REAR PASSENGER'S SIDE INSIDE DOOR HANDLE LIGHT
