BMW X5 M F95 (2019-2023) rear passenger's side convenient entry switch 2 Wiring diagram
This page shows the only wiring diagram for the component.rear passenger's side convenient entry switch 2, which is found in the car BMW X5 M F95 (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear passenger's side convenient entry switch 2 (1 of 1)
BLK WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GRN/YEL WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HALL EFFECT SENSOR
REAR FRONT PASSENGER SIDE SEAT MODULE
REAR PASSENGER'S SIDE CONVENIENT ENTRY SWITCH
REAR PASSENGER'S SIDE CONVENIENT ENTRY SWITCH 2
REAR PASSENGER'S SIDE FORWARD/ BACK SEAT ADJUSTMENT DRIVE
REAR PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
RED/BLK WIRE
RED/BRN WIRE
RIGHT SEAT BENCH MICROSWITCH
RIGHT SEAT BENCH MICROSWITCH 2
SEATS SYSTEM
SERVOMOTOR
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Right memory rear seat circuit (2 of 2) -> REAR PASSENGER'S SIDE CONVENIENT ENTRY SWITCH 2
