BMW X5 M F95 (2019-2023) inlet camshaft sensor 2 Wiring diagram
This page shows the only wiring diagram for the component.inlet camshaft sensor 2, which is found in the car BMW X5 M F95 (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram inlet camshaft sensor 2 (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU/WHT WIRE
BRN WIRE
EXHAUST VANOS SOLENOID ACTUATOR 2
GRN WIRE
IGNITION COIL CYLINDER 5
IGNITION COIL CYLINDER 6
IGNITION COIL CYLINDER 7
IGNITION COIL, CYLINDER 8
INLET CAMSHAFT SENSOR 2
INTAKE VANOS SOLENOID ACTUATOR 2
KNOCK SENSOR 3
KNOCK SENSOR 4
NCA WIRE
OXYGEN SENSOR AFTER CATALYTIC CONVERTER 2
QUANTITY CONTROL VALVE 2
RED WIRE
RED/GRN WIRE
SPARK PLUG
TANK VENT VALVE 2
VIO/RED WIRE
WHT WIRE
WHT/RED WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Wiring diagram engine performance 4.4l turbo (8 of 11) -> INLET CAMSHAFT SENSOR 2
