BMW X5 M F95 (2019-2023) injector cylinder 3 Wiring diagram
This page shows the only wiring diagram for the component.injector cylinder 3, which is found in the car BMW X5 M F95 (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram injector cylinder 3 (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
CRASH SAFETY MODULE
DIGITAL MOTOR ELECTRONICS 2 (LEFT FRONT CORNER OF ENGINE COMPT)
ELECTRIC FUEL PUMP CONTROL ELECTRONICS
GRN WIRE
GRN/GRY WIRE
INJECTOR CYLINDER 1
INJECTOR CYLINDER 2
INJECTOR CYLINDER 3
INJECTOR CYLINDER 4
NCA WIRE
RED WIRE
RED/GRN WIRE
VIO/RED WIRE
WHT WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 4.4l turbo (6 of 11) -> INJECTOR CYLINDER 3
