BMW X5 M F95 (2019-2023) front passenger's door automatic soft close drive unit Wiring diagrams
This page contains all the electrical diagrams for the component. front passenger's door automatic soft close drive unit, in which he is found in the car BMW X5 M F95 (2019-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram front passenger's door automatic soft close drive unit (1 of 2)
BLK/BRN WIRE
BLK/GRY WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DEADLOCKING DRIVE
FRONT PASSENGER DOOR LOCK
FRONT PASSENGER'S DOOR AUTOMATIC SOFT CLOSE DRIVE UNIT
GRY/YEL WIRE
HKFM
LEFT LOWER TRUNK LID LOCK
LEFT SOFT-CLOSE AUTOMATIC LOWER TRUNK LID
ORG/ WIRE
RED/GRN WIRE
RIGHT LOWER TRUNK LID LOCK
RIGHT SOFT-CLOSE AUTOMATIC LOWER TRUNK LID
ROTARY STRIKER SWITCH HALL EFFECT SENSOR
UNLOCKING, LOCKING MECHANISM DRIVE
VIO/GRY WIRE
W/ AUTOMATIC SOFT CLOSE SYSTEM
W/O AUTOMATIC SOFT CLOSE SYSTEM
WHT/BRN WIRE
WHT/GRY WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Anti-theft & central locking circuit (4 of 5) -> FRONT PASSENGER'S DOOR AUTOMATIC SOFT CLOSE DRIVE UNIT
Wiring diagram front passenger's door automatic soft close drive unit (2 of 2)
BLK/BRN WIRE
BLK/GRY WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DEADLOCKING DRIVE
FRONT PASSENGER DOOR LOCK
FRONT PASSENGER'S DOOR AUTOMATIC SOFT CLOSE DRIVE UNIT
GRY/YEL WIRE
HKFM
LEFT LOWER TRUNK LID LOCK
LEFT SOFT-CLOSE AUTOMATIC LOWER TRUNK LID
ORG/ WIRE
RED/GRN WIRE
RIGHT LOWER TRUNK LID LOCK
RIGHT SOFT-CLOSE AUTOMATIC LOWER TRUNK LID
ROTARY STRIKER SWITCH HALL EFFECT SENSOR
UNLOCKING, LOCKING MECHANISM DRIVE
VIO/GRY WIRE
W/ AUTOMATIC SOFT CLOSE SYSTEM
W/O AUTOMATIC SOFT CLOSE SYSTEM
WHT/BRN WIRE
WHT/GRY WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Power door locks circuit (4 of 5) -> FRONT PASSENGER'S DOOR AUTOMATIC SOFT CLOSE DRIVE UNIT
