BMW X5 M F85 (2014-2018) Charging circuit

3.0L TURBO DIESEL 4.4L TURBO 3.0L TURBO 4.4L TURBO ALTERNATOR AUXILIARY BATTERY BATTERY BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DC/DC CONVERTER FUSE 506 INTELLIGENT BATTERY SENSOR JUMP START TERMINAL POINT NCA WIRE POWER CONTROL UNIT RADIATOR SHUTTER DRIVE UNIT RED WIRE RED/BLU WIRE SAFETY BATTERY TERMINAL GAS GENERATOR STARTER TRANSFER TERMINAL POINT VIO WIRE
