BMW X5 M F85 (2014-2018) passenger's seat backrest width adjustment drive Wiring diagram
This page shows the only wiring diagram for the component.passenger's seat backrest width adjustment drive, which is found in the car BMW X5 M F85 (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's seat backrest width adjustment drive (1 of 1)
ACTUATOR MOTOR
ACTUATOR MOTOR PASSENGER SEAT BACKREST WIDTH ADJUSTMENT DRIVE 2
BLK/GRN WIRE
BLU/BRN WIRE
BLU/YEL WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/ORG WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FRONT PASSENGER SEAT BACKREST ANGLE ADJUSTMENT DRIVE
FRONT PASSENGER SEAT MODULE
FRONT PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK
GRY/GRN WIRE
GRY/WHT WIRE
HALL SENSOR
PASSENGER'S SEAT BACKREST HEAD ADJUSTMENT DRIVE
PASSENGER'S SEAT BACKREST WIDTH ADJUSTMENT DRIVE
PASSENGER'S SEAT HEADREST HEIGHT ADJUSTMENT DRIVE
RED WIRE
SEATS SYSTEM
SERVO MOTOR
W/ MULTI- FUNCTION SEAT
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Passenger"s memory seat circuit (2 of 2) -> PASSENGER'S SEAT BACKREST WIDTH ADJUSTMENT DRIVE
