BMW X5 M F85 (2014-2018) mirr heater Wiring diagram
This page shows the only wiring diagram for the component.mirr heater, which is found in the car BMW X5 M F85 (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirr heater (1 of 1)
BLU/RED WIRE
BLU/YEL WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER EXTERIOR MIRROR
DRIVER'S DOOR SWITCH BLOCK
FRONT PASSENGER EXTERIOR MIRROR
FRONT POWER DISTRIBUTION BOX
FUSE 22
FUSE 509
GRN/YEL WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL
LIN BUS SIG
MIRR HEATER
MIRROR HEATER
PT CAN H
PT CAN L
RED WIRE
RED/GRY WIRE
SUPPLY
Go to component -> Heated mirrors circuit, w/o lin bus function -> MIRR HEATER
