BMW X5 M F85 (2014-2018) left seat bench microswitch 2 Wiring diagram
This page shows the only wiring diagram for the component.left seat bench microswitch 2, which is found in the car BMW X5 M F85 (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left seat bench microswitch 2 (1 of 1)
BLU WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 509
GRN WIRE
HOT AT ALL TIMES
LEFT SEAT BENCH MICROSWITCH
LEFT SEAT BENCH MICROSWITCH 2
LEFT SEAT BENCH MICROSWITCH 3
RED WIRE
RIGHT SEAT BENCH MICROSWITCH
W/ COMFORTABLE BENCH
W/O COMFORTABLE BENCH
WHT WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Second row seat locking circuit -> LEFT SEAT BENCH MICROSWITCH 2
