BMW X5 M F85 (2014-2018) hall sensor gnd hall sensor signal Wiring diagram
This page shows the only wiring diagram for the component.hall sensor gnd hall sensor signal, which is found in the car BMW X5 M F85 (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hall sensor gnd hall sensor signal (1 of 1)
ACT PANORAMA GLASS ROOF
ACT SLIDE/TILT SNRF
BLU WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 20
FUSE 28
FUSE 38
GRN WIRE
GRY/BLK WIRE
HALL SENSOR GND
HALL SENSOR GND HALL SENSOR SIGNAL
HALL SENSOR SIGNAL
HALL SENSOR SIGNAL ACT PANORAMA GLASS ROOF
HOT AT ALL TIMES
HOT W/
K-CAN BUS SIGNAL
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/WHT WIRE
RELAY ENERGIZED
ROOF FUNCTION CENTER
SLIDE/TILT SUNROOF DRIVE UNIT (CENTER FRONT OF ROOF)
SPLY TER 30
SUNROOF SHADE DRIVE
TERM 30 PWR SPLY
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Power top/sunroof circuit -> HALL SENSOR GND HALL SENSOR SIGNAL
