BMW X5 M F85 (2014-2018) engine oil pressure, temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.engine oil pressure, temperature sensor, which is found in the car BMW X5 M F85 (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine oil pressure, temperature sensor (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DIGITAL MOTOR ELECTRONICS
DME MAIN RELAY
ELECTRICAL WASTEGATE VALVE
ENGINE OIL PRESSURE, TEMPERATURE SENSOR
EXHAUST VANOS SOLENOID ACTUATOR
FUSE 1
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
GRN WIRE
GRY WIRE
IGNITION, FUEL INJECTION RELAY
PNK WIRE
RED WIRE
ROTOR POSITION SENSOR
VALVETRONIC RELAY
WHT WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo hybrid (5 of 12) -> ENGINE OIL PRESSURE, TEMPERATURE SENSOR
