BMW X5 M F85 (2014-2018) changeover valve actuating flap high pressure compressor 2 Wiring diagram

BLK WIRE BLK/GRY WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRAKE LIGHT SWITCH BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/YEL WIRE BUS SIG BYPASS ACTIVATION CAMSHAFT SENS GND CAMSHAFT SENS SIG CHANGEOVER VALVE ACTUATING FLAP HIGH PRESSURE COMPRESSOR 2 CHARGING PRESS SIG COOLER ACTIVATION CRANKSHAFT SENS SIG DDE RLY DIESEL PARTICULATE SENSOR DIGITAL DIESEL ELECTRONICS EGR ACTUATOR EGR ACTUATOR SIG ENGINE COMPARTMENT POWER DISTRIBUTION BOX FUEL INJ 4 CYL 4 FUEL INJ 4 CYL 5 FUEL INJ 4 CYL 6 FUSE 403 GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/RED WIRE HI PRESS SIG HOT AT ALL TIMES LIN BUS SIG METER GND NITROGEN OXIDE SENSOR AFTER SCR CATALYTIC CONVERTER OIL CONDITION SENSOR OIL PRESS SENS SIG OIL PRESSURE SWITCH OXYGEN SENS SIG PNK WIRE PRESS SENS SIG PRESSURE CONVERTER FOR WASTEGATE VALVE RAIL PRESS SENS GND RAIL PRESS SENS SIG RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SENS GND STARTING/ CHARGING SYSTEM SW SIG TEMP SENS SIG TERM 15 THROTTLE VLV SIG TURBOCHARGER SIG VIO WIRE VIO/BLK WIRE WASTEGATE VALVE SIG WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE
