BMW X5 M F85 (2014-2018) activation servomotor lockout Wiring diagram
This page shows the only wiring diagram for the component.activation servomotor lockout, which is found in the car BMW X5 M F85 (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram activation servomotor lockout (1 of 1)
ACTIVATION SERVOMOTOR
ACTIVATION SERVOMOTOR LOCKOUT
ACTIVE STEERING (REAR OF LEFT FRONT WHEELWELL)
ACTIVE STEERING SERVOMOTOR (ON STEERING RACK)
BLK WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BLU WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
ELECTRIC SERVOMOTOR LOCK
FLEXRAY BUS SIG
FRONT POWER DISTRIBUTION BOX
FUSE 44
FUSE 59
GRN WIRE
HOT AT ALL TIMES
HOT W/
NCA WIRE
PNK/BLU WIRE
POWER DISTRIBUTION SYSTEM
RED/BLU WIRE
RELAY ENERGIZED
SERVOMOTOR SIG
SERVOMOTOR SPLY
TERMINAL 15 SPLY
TERMINAL 30 SPLY
VIO WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component -> Active power steering circuit -> ACTIVATION SERVOMOTOR LOCKOUT
