BMW X5 M E70 facelift (2010-2013) right rear side window tv aerial Wiring diagram
This page shows the only wiring diagram for the component.right rear side window tv aerial, which is found in the car BMW X5 M E70 facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear side window tv aerial (1 of 1)
BLU WIRE
BRN WIRE
CAR INFORMATION COMPUTER CIC
FUSE 119
GRN WIRE
HOT W/ TERMINAL
LEFT SIDE WINDOW ANTENNA
LEFT SIDE WINDOW ANTENNA AMPLIFIER
MOST DATA BUS CIRCUIT
NAVIGATION SYSTEM
NCA WIRE
REAR LID TV AMPLIFIER
REAR POWER DISTRIBUTION BOX
REAR SEAT ENTERTAINMENT
REAR-WINDOW AERIAL
RED WIRE
RIGHT REAR SIDE WINDOW TV AERIAL
RIGHT TV AMPLIFIER
VIDEO MODULE (BEHIND LEFT QUARTERPANEL)
WHT WIRE
YEL/BLK WIRE
Go to component -> Video system circuit -> RIGHT REAR SIDE WINDOW TV AERIAL
