BMW X5 M E70 facelift (2010-2013) rear driver's side door system lock Wiring diagram
This page shows the only wiring diagram for the component.rear driver's side door system lock, which is found in the car BMW X5 M E70 facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear driver's side door system lock (1 of 1)
BRN WIRE
CAMERA BASED DRIVER SUPPORT SYSTEMS
CAR ACCESS SYSTEM
DRIVER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE
DRIVER'S DOOR ENTRANCE LIGHT
DRIVER'S DOOR EXIT LIGHT
DRIVER'S DOOR HANDLE PLATE LIGHTING
DRIVER'S DOOR ODDMENTS COMPARTMENT LIGHTING
DRIVER'S DOOR SWITCH BLOCK
DRIVER'S DOOR SYSTEM LOCK
DRIVER'S LUMBAR SUPPORT SWITCH
DRIVER'S LUMBAR SUPPORT VALVE BLOCK
DRIVER'S SEAT ADJUSTMENT SWITCH
DRIVER'S SEAT HEATING MODULE
DRIVER'S SEAT MODULE
DRIVER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE
DRIVER'S SIDE OUTSIDE MIRROR
DYNAMIC STABILITY CONTROL (DSC)
FOOTWELL MODULE
HEATING/ AIR CONDITIONING SYSTEM
LEFT FRONT FOOTWELL LIGHT
LEFT REAR AUTOMATIC SOFT-CLOSE DRIVE
LEFT REAR DOOR COURTESY LIGHTING
LEFT REAR DOOR EXIT LIGHT
LEFT REAR ELECTRONIC OUTER DOOR HANDLE PLATE LIGHTING
LEFT REAR ODDMENTS COMPARTMENT LIGHTING
LEFT REAR OUTER DOOR HANDLE ELECTRONIC MODULE
OBDII SOCKET
REAR DRIVER'S SIDE DOOR SYSTEM LOCK
REAR DRIVER'S SIDE POWER WINDOW SWITCH
SERVOTRONIC
STEERING COLUMN SWITCH CLUSTER
W/ MEMORY
W/O LUMBER SUPPORT
W/O MEMORY
Go to component -> Ground distribution circuit (2 of 6) -> REAR DRIVER'S SIDE DOOR SYSTEM LOCK
