Instrument illumination circuit for BMW X4 G02 facelift (2021-2024)

AIR CONDITIONING (BEHIND GLOVE BOX) AIR CONDITIONING SYSTEM AUTOMATIC REAR AIR CONDITIONING OPERATING FACILITY BLK WIRE BLU WIRE BLU/VIO WIRE BODY DOMAIN CONTROLLER (RIGHT KICK PANEL) BRN WIRE BRN/BLK WIRE FRONT CENTER VENTILATION GRILLE FUSE 10 FUSE 29 GRN WIRE GRY/GRN WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT W/ BI-STABLE RELAY ENERGIZED LEFT FRONT VENTILATION GRILLE LIGHT OPERATING UNIT OVERHEAD CONSOLE REAR AIR VENTILATION GRILLE RED WIRE RED/BLU WIRE RIGHT END OF DASH) RIGHT FRONT POWER DISTRIBUTION BOX RIGHT FRONT VENTILATION GRILLE ROOF FUNCTION CENTER USB CHARGING PORT 6 USB CHARGING SOCKET 3 WHT/BLU WIRE WHT/VIO WIRE WHT/YEL WIRE WIRELESS CHARGING STORAGE

BRN WIRE BRN/BLK WIRE BRN/ORG WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR CENTRAL LOCKING BUTTON DRIVER'S DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS DRIVER'S SIDE REAR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS DRIVER'S SIDE REAR POWER WINDOW SWITCH FRONT PASSENGER DOOR CENTRAL LOCKING BUTTON FRONT PASSENGER DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS FRONT PASSENGER DOOR POWER WINDOW SWITCH GRY/RED WIRE PASSENGER SIDE REAR POWER WINDOW SWITCH PASSENGER'S SIDE REAR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS REFUELING BUTTON VEHICLE INTERIOR TAILGATE BUTTON WHT/BLU WIRE WHT/VIO WIRE WHT/YEL WIRE
