BMW X4 G02 facelift (2021-2024) basic high wiring diagram
This page shows the only wiring diagram for the component.basic high, which is found in the car BMW X4 G02 facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
basic high wiring diagram (1 of 1)
AUDIO MODE/HEATING, AIR CONDITIONING SYSTEM CONTROL PANEL
BASIC HIGH
BLK WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/BLK WIRE
CAMERA BASED DRIVER SUPPORT SYSTEMS
COMPUTER DATA LINES SYSTEM
DRIVER ASSISTANCE SYSTEM OPERATING FACILITY W/ HAZARD WARNING SWITCH
DRIVER VEHICLE EXTERIOR MIRROR
DRIVER'S DOOR SWITCH BLOCK
ELECTRONICS
ETHERNET SWITCH (IF EQUIPPED) (LEFT KICK PANEL)
FRONT PASSENGER VEHICLE EXTERIOR MIRROR
FUSE 10
FUSE 204
GRN WIRE
GRN/BLU WIRE
HOT W/ BI-STABLE RELAY ENERGIZED
HOT W/ TERMINAL
KAFAS CAMERA HEATING
LANE CHANGE WARNING LED
MIRROR
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/GRN WIRE
VIO/YEL WIRE
W/ ETHERNET SWITCH
W/O ETHERNET SWITCH
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
Go to component -> Lane departure warning circuit, w/ camera -> BASIC HIGH
