Starting circuit for BMW X4 M F98 (2019-2021)
Starting circuit
BATTERY
BLK WIRE
BLK/WHT WIRE
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN WIRE
CHARGING CIRCUIT
COMPUTER DATA LINES SYSTEM
DIGITAL MOTOR ELECTRONICS
ELECTRONIC TRANSMISSION CONTROL
ENGINE COMPARTMENT POWER DISTRIBUTION BOX
FUSE 29
FUSE BOX
GRN/BLU WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
NCA WIRE
PNK WIRE
PNK/BLU WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT POWER DISTRIBUTION BOX
START-STOP BUTTON
STARTER MOTOR
VIO WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRY WIRE
