Base radio circuit, w/ active sound design for BMW X4 M F98 (2019-2021)

Base radio circuit, w/ active sound design (1 of 5)

X4 M BMW F98 (2019-2021): Base radio circuit, w/ active sound design (1 of 5)

Get access

ANTENNA DIVERSITY ANTENNA DIVERSITY 2 BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 212 GPS AERIAL GRN WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE HEAD UNIT HOT W/ TERMINAL INFOTAINMENT FAN MICROPHONE 2 + MOST DATA BUS CIRCUIT NCA WIRE REAR POWER DISTRIBUTION BOX REAR WINDOW ANTENNA RED WIRE RED/BLK WIRE RED/WHT WIRE SDARS AERIAL SOUND SYSTEMS TELEPHONE AERIAL USED) VIDEO MODULE W/ TELEMATICS W/O TELEMATICS WHT WIRE WHT/BRN WIRE WHT/RED WIRE

Base radio circuit, w/ active sound design (2 of 5)

X4 M BMW F98 (2019-2021): Base radio circuit, w/ active sound design (2 of 5)

Get access

BLK/BRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FUSE 216 FUSE 61 GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE HOT W/ TERMINAL LEFT FRONT BASS SPEAKER LEFT FRONT MID-RANGE SPEAKER LEFT REAR MID-RANGE SPEAKER MICROPHONE (W/O TELEMATICS) NCA WIRE REAR POWER DISTRIBUTION BOX RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT END OF DASH) RIGHT FRONT POWER DISTRIBUTION BOX USED) W/ TELEMATICS W/O TELEMATICS WHT WIRE WHT/BRN WIRE WHT/RED WIRE WIRELESS CHARGING SELF ANTENNA AMPLIFIER WIRELESS CHARGING STORAGE YEL WIRE

Base radio circuit, w/ active sound design (3 of 5)

X4 M BMW F98 (2019-2021): Base radio circuit, w/ active sound design (3 of 5)

Get access

BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM CONTROLLER FUSE 218 GRY WIRE GRY/BRN WIRE GRY/RED WIRE HOT W/ NCA WIRE REAR POWER DISTRIBUTION BOX RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT BASS SPEAKER RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR MID-RANGE SPEAKER WHT WIRE WHT/BRN WIRE WHT/RED WIRE

Base radio circuit, w/ active sound design (4 of 5)

X4 M BMW F98 (2019-2021): Base radio circuit, w/ active sound design (4 of 5)

Get access

BASIS BLK WIRE BLU WIRE BODY DOMAIN CONTROLLER BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM EMERGENCY LOUDSPEAKER GPS ANTENNA GRN WIRE GRN/BLU WIRE GRY WIRE NCA WIRE ORG/ WIRE RED WIRE RED/YEL WIRE ROOF ANTENNA SDARS ANTENNA TELEMATIC COMMUNICATION BOX (REAR CENTER OF ROOF) TELEMATICS ANTENNA TELEPHONE ANTENNA USB PORT 2 WHT WIRE WHT/BLU WIRE

Base radio circuit, w/ active sound design (5 of 5)

X4 M BMW F98 (2019-2021): Base radio circuit, w/ active sound design (5 of 5)

Get access

BASIC VERSION BASIS BLK WIRE BLU WIRE BLUETOOTH ANTENNA BRN WIRE BRN/WHT WIRE CENTRAL INFORMATION DISPLAY FUSE 214 GRN WIRE GRN/BLU WIRE HEAD UNIT HIGH VERSION HOT W/ TERMINAL INSTRUMENT PANEL MICROPHONE (W/ TELEMATICS) NCA WIRE ORG/ WIRE REAR POWER DISTRIBUTION BOX RED WIRE RED/YEL WIRE USB CONNECTION USED) WHT WIRE WLAN ANTENNA
