Anti-lock brakes circuit for BMW X4 M F98 (2019-2021)
Anti-lock brakes circuit (1 of 2)
AUTOMATIC HOLD BUTTON
AUTOMATIC HOLD FUNCTION LED
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DYNAMIC STABILITY CONTROL (DSC)
ENGINE COMPARTMENT POWER DISTRIBUTION BOX
FUSE 28
FUSE 29
FUSE 32
FUSE 404
GRN/BLU WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
LEFT FRONT BRAKE PAD WEAR SENSOR
NCA WIRE
PARKING BRAKE BUTTON
PARKING BRAKE INDICATOR LIGHT
PNK/BLK WIRE
RED WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT END OF DASH)
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT FRONT WHEEL RPM SENSOR
RIGHT PARKING BRAKE DRIVE
RIGHT REAR BRAKE PAD WEAR SENSOR
RIGHT REAR WHEEL RPM SENSOR
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Anti-lock brakes circuit (2 of 2)
BLK WIRE
BLU WIRE
BODY DOMAIN CONTROLLER
BRAKE LIGHT SWITCH
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
CENTER CONSOLE OPERATING FACILITY
COMPUTER DATA LINES SYSTEM
DRIVE EXPERIENCE SWITCH
DTC BUTTON
FUSE 61
GRN WIRE
GRY/BLK WIRE
HILL DESCENT CONTROL BUTTON
LEFT FRONT WHEEL RPM SENSOR
LEFT PARKING BRAKE DRIVE
LEFT REAR WHEEL RPM SENSOR
NCA WIRE
PNK/BLU WIRE
RED WIRE
RED/WHT WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
RIGHT FRONT POWER DISTRIBUTION BOX
STEERING COLUMN SWITCH CLUSTER
WHT WIRE
WHT/YEL WIRE
