Independent heating circuit for BMW X4 M F98 (2019-2021)
Independent heating circuit
AUTOMATIC A/C CIRCUIT
AUXILIARY HEATER COOLANT CHANGEOVER VALVE
AUXILIARY HEATER FUEL METERING PUMP
AUXILIARY HEATER RECIRCULATING PUMP
BLK WIRE
BLK/RED WIRE
BRN WIRE
BRN/GRN WIRE
FUSE 54
GRN WIRE
GRY/GRN WIRE
HOT W/
INDEPENDENT AUXILIARY HEATER
RED WIRE
RED/GRN WIRE
RED/VIO WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
RIGHT FRONT POWER DISTRIBUTION BOX
WHT/BRN WIRE
