Receiver audio module circuit, base for BMW X3 G01 (2017-2021)

ACOUSTIC PEDESTRIAN PROTECTION SPEAKER ACOUSTIC PEDESTRIAN PROTECTION SPEAKER 2 BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BRN WIRE CENTER FRONT MID-RANGE SPEAKER COMPUTER DATA LINES SYSTEM CONTROLLER FUSE 212 FUSE 220 FUSE 61 GRN/BLU WIRE GRN/BRN WIRE GRN/RED WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE HEAD UNIT HOT W/ TERMINAL LEFT FRONT BASS SPEAKER LEFT REAR MID-RANGE SPEAKER MICROPHONE 2 + NCA WIRE REAR POWER DISTRIBUTION BOX RECEIVER AUDIO MODULE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/YEL WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT POWER DISTRIBUTION BOX RIGHT REAR MID-RANGE SPEAKER WHT WIRE WHT/BRN WIRE WHT/RED WIRE WLAN ANTENNA YEL WIRE

BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BLUETOOTH ANTENNA BODY DOMAIN CONTROLLER BRN/WHT WIRE COMPUTER DATA LINES SYSTEM EMERGENCY LOUDSPEAKER FUSE 13 GPS ANTENNA GRN WIRE GRN/BLU WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE HOT W/ BI-STABLE RELAY ENERGIZED LEFT FRONT MID-RANGE SPEAKER MICROPHONE NCA WIRE RECEIVER AUDIO MODULE RED WIRE RED/YEL WIRE RIGHT FRONT MID-RANGE SPEAKER ROOF ANTENNA SDARS ANTENNA TELEMATIC COMMUNICATION BOX (IF EQUIPPED) (REAR CENTER OF ROOF) W/ TELEMATICS W/O TELEMATICS WHT WIRE WHT/BLU WIRE YEL WIRE

ANTENNA SIGNAL AMPLIFIER 2 ANTENNA SIGNAL AMPLIFIER 3 BLK WIRE BLU WIRE BRN WIRE CARD READER CENTRAL INFORMATION DISPLAY GPS ANTENNA GRN WIRE GRN/BLU WIRE HEAD UNIT INSTRUMENT PANEL LEFT "C" PILLAR) LEFT SIDE WINDOW ANTENNA NCA WIRE ORG/ WIRE REAR SPOILER ANTENNA REAR WINDOW ANTENNA RED WIRE RED/YEL WIRE RIGHT SIDE WINDOW ANTENNA SDARS ANTENNA USB CHARGING SOCKET 3 USB CONNECTION USB PORT WHT WIRE WHT/BLU WIRE
