BMW X3 G01 (2017-2021) wht Wiring diagrams

ADJUSTMENT DRIVE BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BODY DOMAIN CONTROLLER BRN WIRE BRN/WHT WIRE CAMERA COMPUTER DATA LINES SYSTEM CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS DRIVER EXTERIOR MIRROR DRIVER'S DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS DRIVER'S DOOR SWITCH BLOCK ELECTROCHROMIC MIRROR EXTERIOR MIRROR FRONT PASSENGER EXTERIOR MIRROR FUSE 67 FUSE 68 GRN WIRE GRY WIRE HOT W/ TERMINAL LANE CHANGE WARNING LED MIRROR ELECTRONICS MIRROR FOLD- IN DRIVE MIRROR HEATING NAVIGATION SYSTEM RED WIRE RED/GRN WIRE RED/GRY WIRE RIGHT FRONT POWER DISTRIBUTION BOX SIDE REPEATER TRUNK, TAILGATE, FUEL DOORS SYSTEM WHT WIRE WHT/BRN WIRE YEL WIRE

ADJUSTMENT DRIVE BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BODY DOMAIN CONTROLLER BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS DEFOGGER SYSTEM DRIVER EXTERIOR MIRROR DRIVER'S DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS DRIVER'S DOOR SWITCH BLOCK EXTERIOR MIRROR CAMERA FRONT PASSENGER EXTERIOR MIRROR FUSE 67 GRN WIRE GRY WIRE HOT W/ MIRROR HEATING NAVIGATION SYSTEM RED WIRE RED/GRN WIRE RED/GRY WIRE RELAY ENERGIZED RIGHT FRONT POWER DISTRIBUTION BOX SIDE REPEATER TRUNK, TAILGATE, FUEL DOORS SYSTEM WHT WIRE WHT/BRN WIRE YEL WIRE

BLK WIRE BLU WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BODY DOMAIN CONTROLLER BRN WIRE DRIVER'S SEAT BELT BUCKLE CONTACT DYNAMIC STABILITY CONTROL (DSC) FRONT PASSENGER SEAT HEATING ELECTRONICS FRONT PASSENGER SEAT MODULE FRONT PASSENGER SEAT OCCUPANCY DETECTION EVALUATION ELECTRONICS FRONT PASSENGER'S SEAT BELT BUCKLE CONTACT GRN WIRE GRN/BLU WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE LEFT REAR SEAT BELT BUCKLE CONTACT NCA WIRE PNK/BLK WIRE PNK/BLU WIRE REAR CENTER SEAT BELT BUCKLE CONTACT RED WIRE RIGHT REAR SEAT BELT BUCKLE CONTACT W/ MEMORY W/ MEMORY W/O MEMORY W/O MEMORY WHT WIRE WHT/BLU WIRE

BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE DRIVER RETRACTOR TENSIONER DRIVER SEAT POSITION SENSOR DRIVER SIDE AIR BAG GAS GENERATOR FRONT PASSENGER AIR BAG GAS GENERATORS FRONT PASSENGER BELT FORCE LIMITER GAS GENERATOR FRONT PASSENGER RETRACTOR TENSIONER FRONT PASSENGER SEAT OCCUPANCY DETECTION SEAT CUSHION HEATER/SENSOR FRONT PASSENGER SEAT POSITION SENSOR FRONT PASSENGER THIGH SUPPORT GRN/BLU WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/VIO WIRE LEFT REAR RETRACTOR TENSIONER NCA WIRE ORG/ WIRE ORG/YEL WIRE RIGHT REAR RETRACTOR TENSIONER VIO/GRN WIRE VIO/WHT WIRE W/ AIR FRESHENER W/ EXTENDIBLE THIGH SUPPORT WHT WIRE WHT/BLK WIRE WHT/BRN WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE

BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CRASH SAFETY MODULE DRIVER BELT FORCE LIMITER GAS GENERATOR DRIVER KNEE AIR BAG GAS GENERATOR DRIVER'S AIR BAG GAS GENERATORS FRONT PASSENGER KNEE AIR BAG GAS GENERATOR FRONT PASSENGER SIDE AIR BAG GAS GENERATOR FUSE 252 FUSE BOX GRN WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE HOT W/ TERMINAL LEFT REAR PEDESTRIAN PROTECTION ACTUATOR NCA WIRE ORG/ WIRE REAR POWER DISTRIBUTION BOX RED/BLU WIRE RELAY ENERGIZED RIGHT REAR PEDESTRIAN PROTECTION ACTUATOR STARTER UNIT SAFETY BATTERY TERMINAL GAS GENERATOR STEERING COLUMN SWITCH CLUSTER STEERING WHEEL) VIO/GRN WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/BRN WIRE YEL WIRE YEL/BLK WIRE

BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FULLY AUTOMATIC TOWING HITCH DRIVE FUSE 282 FUSE 284 GRN WIRE GRY/BLK WIRE GRY/RED WIRE GRY/WHT WIRE HOT W/ TERMINAL REAR POWER DISTRIBUTION BOX RED WIRE RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/VIO WIRE RED/YEL WIRE RELAY ENERGIZED TRAILER MODULE (RIGHT REAR QUARTERPANEL) TRAILER SOCKET SWITCH W/ FULLY AUTOMATIC TOWING HITCH DRIVE W/O FULLY AUTOMATIC TOWING HITCH DRIVE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE

BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/GRY WIRE BLU/WHT WIRE BRN WIRE DIGITAL MOTOR ELECTRONICS ELECTRICAL WASTEGATE VALVE ENGINE VENTILATION HEATING EXHAUST VANOS SOLENOID ACTUATOR FUEL VENT VALVE HOT FILM AIR MASS METER INTAKE AIR TEMPERATURE SENSOR INTAKE VANOS SOLENOID ACTUATOR NCA WIRE OXYGEN SENSOR AFTER CATALYTIC CONVERTER OXYGEN SENSOR BEFORE CATALYTIC CONVERTER QUANTITY CONTROL VALVE RAIL PRESSURE SENSOR RED/GRN WIRE ROTOR POSITION SENSOR VENTURI NOZZLE PRESSURE SENSOR VIO WIRE W/ HOT FILM AIR MASS METER W/O HOT FILM AIR MASS METER WHT WIRE WHT/GRN WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE YEL/WHT WIRE

BLK WIRE BLK/BLU WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BOOST PRESSURE SENSOR BRN WIRE CHARGE AIR TEMPERATURE/ INTAKE MANIFOLD PRESSURE SENSOR CRANKCASE COOLANT SHUT-OFF VALVE DIGITAL MOTOR ELECTRONICS (LEFT REAR ENGINE COMPT) EXHAUST CAMSHAFT SENSOR GRN WIRE HEAT MANAGEMENT MODULE (FRONT OF ENGINE) INTAKE AIR TEMPERATURE SENSOR INTAKE CAMSHAFT SENSOR OIL PRESSURE CONTROL VALVE POSITION SENSOR RED WIRE RED/GRN WIRE VALVETRONIC SERVOMOTOR (LEFT FRONT OF CYLINDER HEAD) VIO WIRE W/ HOT FILM AIR MASS METER WHT WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE YEL/WHT WIRE

BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BRN WIRE COOLANT EXPANSION SHUT-OFF VALVE COOLANT TEMPERATURE SENSOR CRANKSHAFT SENSOR ENGINE COMPARTMENT POWER DISTRIBUTION BOX ENGINE OIL PRESSURE SENSOR FUSE 406 HOT AT ALL TIMES IGNITION COIL CYLINDER 1 IGNITION COIL CYLINDER 2 IGNITION COIL CYLINDER 4 KNOCK SENSOR KNOCK SENSOR #2 LOW TEMPERATURE COOLANT CIRCUIT COOLANT PUMP NCA WIRE OIL LEVEL SENSOR RED WIRE RED/GRN WIRE SPARK PLUG TURBOCHARGER COOLANT PUMP VIO WIRE WHT WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/RED WIRE YEL/WHT WIRE

ACCELERATOR PEDAL MODULE BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/RED WIRE BLU WIRE BLU/YEL WIRE BRAKE LIGHT SWITCH BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/GRY WIRE COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM DIGITAL MOTOR ELECTRONICS ELECTRICAL EXHAUST FLAP EXHAUST GAS PRESSURE SENSOR GASOLINE PARTICULATE FILTER FUSE 203 FUSE 501 FUSE BOX GRN WIRE GRN/BRN WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT W/ LIN POWER DISTRIBUTION BOX PNK WIRE PNK/BLU WIRE RADIATOR OUTLET TEMPERATURE SENSOR REAR POWER DISTRIBUTION BOX RED WIRE RED/VIO WIRE RELAY ENERGIZED VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/WHT WIRE
