BMW X3 G01 (2017-2021) rear window defogger rejector circuit 2 Wiring diagram
This page shows the only wiring diagram for the component.rear window defogger rejector circuit 2, which is found in the car BMW X3 G01 (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear window defogger rejector circuit 2 (1 of 1)
AIR CONDITIONING
AUDIO MODE/HEATING, AIR CONDITIONING SYSTEM CONTROL PANEL
BODY DOMAIN CONTROLLER
BRN WIRE
FUSE 231
FUSE 501
FUSE BOX
GRN WIRE
GRN/VIO WIRE
HOT AT ALL TIMES
LIN POWER DISTRIBUTION BOX
REAR POWER DISTRIBUTION BOX
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER REJECTOR CIRCUIT 2
REAR WINDOW HEATING BUTTON
REAR WINDOW HEATING RELAY
RED WIRE
RED/BLU WIRE
YEL/BLK WIRE
Go to component -> Rear defogger circuit -> REAR WINDOW DEFOGGER REJECTOR CIRCUIT 2
