BMW X3 G01 (2017-2021) rear power distribution box lin power distribution box Wiring diagrams
This page contains all the electrical diagrams for the component. rear power distribution box lin power distribution box, in which he is found in the car BMW X3 G01 (2017-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear power distribution box lin power distribution box (1 of 2)
AUDIO MODE/ HEATING, AIR CONDITIONING SYSTEM CONTROL PANEL
BASIC
BLK WIRE
BLU WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
CENTER CONSOLE OPERATING FACILITY
CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS
DRIVER ASSISTANCE SYSTEM OPERATING FACILITY W/ HAZARD WARNING SWITCH
DRIVER'S DOOR SWITCH BLOCK
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
INSIDE STEERING WHEEL)
LEFT MULTI- FUNCTION STEERING WHEEL SWITCH BLOCK
REAR POWER DISTRIBUTION BOX LIN POWER DISTRIBUTION BOX
STEERING COLUMN SWITCH CLUSTER
STEERING WHEEL MODULE
TOUCH DETECTION ELECTRONICS
VIO/YEL WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Computer data lines circuit (9 of 9) -> REAR POWER DISTRIBUTION BOX LIN POWER DISTRIBUTION BOX
Wiring diagram rear power distribution box lin power distribution box (2 of 2)
AUXILIARY BATTERY
BODY DOMAIN CONTROLLER
BOOT LID/ TAILGATE LOCK
BRN WIRE
DYNAMIC STABILITY CONTROL (DSC)
ELECTRIC FAN
ELECTRIC FUEL PUMP CONTROL ELECTRONICS
ELECTRICAL EXHAUST FLAP
FRONT ELECTRIC AUXILIARY HEATER
HKFM
LEFT INNER TAILLIGHT
LEFT LICENSE PLATE LIGHT
LEFT OUTER TAILLIGHT
NCA WIRE
OUTER TAILGATE BUTTON
POWER CONTROL UNIT
REAR POWER DISTRIBUTION BOX LIN POWER DISTRIBUTION BOX
REAR WINDOW DEFOGGER
REAR WIPER
REGULATED REAR AXLE DIFFERENTIAL LOCK
RIGHT INNER TAILLIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT OUTER TAILLIGHT
SCR CONTROL UNIT
SIREN W/ TILT ALARM SENSOR
TRAILER MODULE
TRAILER SOCKET
Go to component -> Ground distribution circuit (7 of 7) -> REAR POWER DISTRIBUTION BOX LIN POWER DISTRIBUTION BOX
